Wen 4214 User Manual

EXPLODED VIEW & PARTS LIST
22
Item # Stock # Description Qty
1 4214B-001 Circlip 1
2 4214B-002 Cam 1
3 4214B-003 Screws M8x12 1
4 4214B-004 Bearing 61907 1
5 4214B-005 Spindel moveable pulley 1
6 4214B-006 V-belt M-36 1
7 4214B-007 Spindle fixed pulley 1
8 4214B-008 Key A type 4x4x64 1
9 4214B-009 Shaft sleeve 1
10 4214B-010 Bearing 6203RZ 2
11 4214B-011 Retainer 1
12 4214B-012 Circlip 1
13 4214B-013 Screw 2
14 4214B-014 Screw ST2.9x6.5 4
15 4214B-015 Counter 1
16 4214B-016 Counter base 1
17 4214B-017 Handle knob 4
18 4214B-018 Variable speed handle 1
19 4214B-019 Lock nut M10 1
20 4214B-020 Flat washer 10 1
21 4214B-021 Handle seat 1
22 4214B-022 Gear base 1
23 4214B-023 Gear shaft 1
24 4214B-024 Key A type 3x3x25 1
25 4214B-025 Nut M12 2
26 4214B-026 Coil spring assembly 1
27 4214B-027 Spring baffle 1
28 4214B-028 Busing 1
29 4214B-029 Speed digital display 1
30 4214B-030 Switch box 1
31 4214B-031 Screw M5x14 3
32 4214B-032 Switch 1
33 4214B-033 Lamp/Laser switch 2
34 4214B-034 Lock knob 2
35 4214B-035 Big washer 4
36 4214B-036 Fence 1
37 4214B-037 Baffle 1
38 4214B-038 Butterfly nut M6 1
39 4214B-039 Bolt M6x16 1
40 4214B-040 Screw M6x12 2
41 4214B-041 Flat washer 5
42 4214B-042 Work table 1
43 4214B-043 Wing nut M8 2
Item # Stock # Description Qty
44 4214B-044 Guide rod 2
45 4214B-045 Roller screw 2
46 4214B-046 Roller support 1
47 4214B-047 Screw M6x12 2
48 4214B-048 Roller 1
49 4214B-049 Column clamp 2
50 4214B-050 Table arm 1
51 4214B-051 Bolt M12x35 1
52 4214B-052 Adjusting nut 4
53 4214B-053 Special washer 1
54 4214B-054 Scale 1
55 4214B-055 Bearing 6201RZ 1
56 4214B-056 Rubber washer 1
57 4214B-057 Quil 1
58 4214B-058 Nut M6 1
59 4214B-059 Scale collar 1
60 4214B-060 Screw M6x16 1
61 4214B-061 Nut M8 5
62 4214B-062 Bearing 6204RZ 1
63 4214B-063 Spindle 1
64 4214B-064 Chuck connection rod 1
65 4214B-065 Chuck 1
66 4214B-066 Screw M5x12 3
67 4214B-067 Cord plate 2
68 4214B-068 Rubber bush 3
69 4214B-069 Cord bush 1
70 4214B-070 Cord fixed plate 2
71 4214B-071 Screw M6x12 5
72 4214B-072 Screw M5x16 1
73 4214B-073 Pulley cover assembly 1
74 4214B-074 Sponge pad 4
75 4214B-075 Pin 6x15 2
76 4214B-076 Screw M8x8 5
77 4214B-077 Screw M5x10 5
78 4214B-078 Wrench clip 1
79 4214B-079 Screw M6x8 2
80 4214B-080 Pin 1
81 4214B-081 fastener set 2
84 4214B-084 Star washer 5 2
85 4214B-085 Quil set screw 1
86 4214B-086 Head 1
87 4214B-087 Lasser 2
88 4214B-088 Spring 1
