Wen 4214 User Manual

EXPLODED VIEW & PARTS LIST
23
Item # Stock # Description Qty
89 4214B-089 Rack shaft 1
90 4214B-090 Big washer 8 1
91 4214B-091 Bolt M8x12 4
92 4214B-092 Screw M3x10 1
93 4214B-093 Lamp socket bracket 1
94 4214B-094 Lamp socket 1
95 4214B-095 LED light 1
96 4214B-096 Screw M4x8 2
97 4214B-097 Indicator 1
98 4214B-098 Rack collar 1
99 4214B-099 Screw M6x10 3
100 4214B-100 Table support 1
101 4214B-101 Worm 1
102 4214B-102 Crank 1
103 4214B-103 Rack 1
104 4214B-104 Column 1
105 4214B-105 Inner gear 1
106 4214B-106 Inner gear shaft 1
107 4214B-107 Bolt M10x30 4
108 4214B-108 Column base 1
109 4214B-109 Base 1
110 4214B-110 Circlip 1
111 4214B-111 Motor fixed pulley 1
112 4214B-112 Motor moveable pulley 1
Item # Stock # Description Qty
113 4214B-113 Spring 1
114 4214B-114 Spring base 1
115 4214B-115 Spring washer 1
116 4214B-116 Motor assembly 1
117 4214B-117 Key A type 4x4x80 1
118 4214B-118 Screw 8x16 4
119 4214B-119 Power cord 1
120 4214B-120 Spring washer 8 3
121 4214B-121 Motor plate 1
122 4214B-122 Handle 3
123 4214B-123 Handle hub 1
124 4214B-124 Elastic ring Type A 55 1
125 4214B-125 Circlip 35 1
126 4214B-126 Circlip 11 1
127 4214B-127 Nut M8 1
128 4214B-128 Spring washer 4 2
129 4214B-129 Handle bar 1
130 4214B-130 Spring 1
131 4214B-131 Sealing rubber strip 1
132 4214B-132 Hex wrench S3 1
133 4214B-133 Hex wrench S4 1
134 4214B-134 Chuck key 1
135 4214B-135 Wedge block 1
136 4214B-136 Wing nut 2
