10
3. Slide the top pulley onto the shaft. This can be difficult, as the spring is trying to push
upward, the bottom pulley and belt must compress the spring in order for the top pulley
to push pass the circlip ring on the motor shaft. A rubber mallet may be used to force the
top pulley onto the shaft, just make sure that the key slot is lined up.
4. Once the pulley assembly is on the shaft, quickly tighten the set screws before the
assembly pops off.
5. Using circlip pliers, put the circlip back on the motor shaft. Make sure the circlip fits into
the circlip groove on the motor shaft. The pulley assembly may have to pushed lower on
the shaft.
QUESTIONS? PROBLEMS?
Contact WEN Customer Service at 1-800-232-1195, M-F, 8-5 CST, or
email techsupport@wenproducts.com
