KNOW YOUR DRILL PRESS
TOOL PURPOSE
Drill presses are mainly used to drill clean, precise cylindrical holes into workpieces or enlarge existing holes. You
may also find other uses for your drill press such as reaming, countersinking, counterboring, tapping, etc. Refer to
the diagram below and on page 10 to become familiarized with the parts and controls of your drill press.
Various drill bits, vises, clamps and other accessories can be purchased from wenproducts.com
Column
Rack
Crank Handle
Column Support
Base
Table Lock Handle
Bevel Lock Bolt
Bevel Scale
Laser ON / OFF Switch
LED Worklight Switch
Extension Wing with
Integrated Rollers
Support Lock Handle
Speed Control Handle
Power Cord
Chuck Key Storage
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
Digital Speed Readout
ON / OFF Switch
Depth Scale
Chuck
Table
Feed Handles
Housing Cover Screw
Housing Cover
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
9
Fig. 2
To Next Page
