Wen 4286 User Manual

15
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty
1 4286-001 Screw (M5x48) 4
2 4286-002 Bolt (M5x51) 2
3 4286-004 I Type Hex Nut (M16 Left) 1
4 4286-005 Flange 4
5 4286-006 Grinding Wheel #120 (P200x25x15.88) 1
6 4276-013 Screw (M5x10) 6
7 4286-009 Spark Deector 2
8 4276-011 Screw (M5x10) 2
9 4286-011 Left Eye Shield Assembly 1
10 4286-012 Left Eye Shield Rod 1
11 4286-010 Flat Washer (D5) 2
12 4276-005 Eye Shield Locking Knob (2) 2
13 4286-014 Flat Washer (D6) 4
14 4276-002 Spring Washer (D6) 2
15 4276-001 Hex Bolt (M6x30) 2
16 4286-017 Left Wheel Guard 1
17 4286-019 Left Toolrest Support 1
18 4286-020 Big Flat Washer (D5) 2
19 4286-021 Work Rest Locking Knob 2
20 4286-022 Left Movable Work Rest 1
21 4286-023 Work Rest Locking Knob 2
22 4276-008 Hex Nut (M5) 4
23 4286-003 Left Wheel Guard Cover 1
24 4286-018 Hex Nut (M5) 4
25 4286-024 End Shield 2
26 4286-025 Wave Washer (D40) 1
27 4286-026 Stator 1
28 4276-023 Grommet 1
29 4276-024 Lock Washer (D4 ) 1
30 4276-033 Screw (M4x8) 2
31 4286-032 Switch 1
32 4286-033 Screw (M5x8) 4
33 4286-034 Switch Plate 1
34 4286-036 Screw (M8x20) 2
35 4286-037 Bottom Plate Cover 1
36 4286-038 Rubber Feet 4
37 4286-039 Screw (M5x16) 4
38 4286-040 Capacitor 1
39 4286-049 Right Eye Shield Support 1
40 4286-008 Lock Washer (D5) 2
41 4286-045 Base (1) 1
42 4286-043 Bearing (204) 2
43 4286-044 Rotor 1
44 4286-046 Cord Plate 1
45 4276-041 Strain Relief 1
46 4276-043 Power Cord 1
47 4286-051 Screw (M5x148) 4
48 4286-054 Right Wheel Guard 1
49 4286-055 Grinding Wheel #60 (P200x25x15.88) 1
50 4286-053 Right Fixed Work Rest 1
51 4286-052 Right Movable Work Rest 1
52 4286-056 I Type Hex Nut (M16 Right) 1
53 4286-057 Right Wheel Guard Cover 1
54 4286-050 Right Eye Shield Assembly 1
