EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 56180-037 Engine Assemly 1
2 56155-002 Fuel Hose Clamp 9 4
3 56180-026 Vent Hose, Tank 1
4 56180-026.1 Fuel Hose Clamp 8 1
5 56180-027 Vent Valve 1
6 56155-006 Fuel Cap 1
7 56155-007 Fuel Tank 1
8 56155-008 Fuel Filter, Fuel Tank 1
9 56180-031 Big Washer 4
10 56180-030 Flange Bolt, M6×20 4
11 56180-026.3 Purge Hose 1
12 56180-034 Fuel Hose 1
13 56180-004 Fuel Cock 1
14 56180-008 Rubber Cushion 4
15 56180-009 Front Case 1
16 56180-009.1 Flange Bolt, M8×20 4
17 56155-017 Rotor 1
18 56155-018 Stator 1
19 56155-019 Fuel Hose Clamp 16 2
20 56180-026.4 Heat-Resistant Hose 1
21 56155-021 Muffler Gasket 1
22 56155-022 Spring Washer 8 3
23 56155-023 Washer 8 2
24 56180-032 Flange Nut, M8 8
25 56155-025 Muffler 1
26 56155-026 Muffler Bracket 1
27 56180-036 Flange Bolt, M6×12 10
28 56180-033.1 Spark Arrestor 1
29 56155-029 Hose Hoop 1
30 56180-013 Engine End Cover 1
31 56180-013.1 Flange Bolt, M5×10 3
32 56155-032 Voltage Regulator (AVR) 1
No. Part No. Description Qty.
33 56155-033 Flange Bolt, M8×185 1
34 56155-034 Flange Bolt, M6×110 4
35 56155-035 Washer 6 4
36 56155-036 Spring Washer 6 4
37 56180-017 Rectifier 1
38 56155-038 Flange Bolt, M5×15 6
39 56155-039 Wiring Plate 1
40 56155-040 Carbon Brush 1
41 56155-041 Motor Housing 1
42 56155-042 Rubber Shock Absorber #2 2
43 56180-016 Rear Cover, Panel 1
44 56155-044 Control Panel 1
45 56155-045 Power Indicator Light 1
46 56180-038 Grounding Nut Assembly 1
47 56180-024 DC 12V Socket 1
48 56180-020 AC Circuit Breaker 1
49 56180-021 DC Circuit Breaker 1
50 56180-022 AC Socket (20A/125V) 1
51 56180-025 Engine Switch 1
52 56180-028 Flange Bolt, M8×15 4
53 56155-053 Washer 4
54 56180-007 Rubber Foot 4
55 56180-029 Nut M8 3
56 56155-056 Frame 1
57 56155-057 Plate, Carbon Tank 1
58 56180-026.2 Carbon Tank 1
59 56155-059 Bracket, Carbon Tank 1
60 56155-060 Back Beam 1
61 56155-061 Flange Bolt, M8×30 2
62 56155-062 Rubber Shock Absorber #1 2
63 56180-023 Engine Bracket 2
64 56155-064 Fuel Gauge 1
