No. Part No. Description Qty.
1 56202i-001 Screw, M4 X 10 5
2 56202i-002 Cable 1
3 56202i-003 Screw, M4 X 16 1
4 56202i-004 Spring Washer, Ø4 1
5 56202i-005 Fuel Valve Lever 1
6 56202i-006 Panel Assembly 1
7 56202i-007 Switch Block 1
8 56202i-008
Circlip, Bearing Holder,
Ø10.8 X Ø6
2
9 56202i-009 Step Bolt 20
10 56202i-010 Protective Panel 1
11 56202i-011 Fuel Valve, Angle 90° 1
12 56202i-012
Hex Head Flange Bolt,
M6 X 14
3
13 56202i-013 Clamp 1, Ø8 2
14 56202i-014 Big Flange Bolt, M6 X 12 14
15 56202i-015 Inverter, 120V 60Hz 1
16 56202i-016 Step Nut 2
17 56202i-017 Engine 79Cc 1
18 56202i-018 Bolt, M5×12 1
19 56202i-019 R-Pin 3
20 56202i-020 Front Air Guide 1
21 56202i-021 Threaded Clamp 12
22 56202i-022 Left Frame 1
23 56202i-023 Shaft Locating Bolt 6
24 56202i-024 Left Cover Panel 1
25 56202i-025 Recoil Starter 1
26 56202i-026 Screw, M5 X 16 4
27 56202i-027 Tube Sheath 1
28 56202i-028 Fuel Tube, 300Mm 1
No. Part No. Description Qty.
29 56202i-029 Clamp 2, Ø9.7 X 8 1
30 56202i-030 Fuel Strainer 1
31 56202i-031 Rubber Pad 2
32 56202i-032 Fuel Tank, 4 L 1
33 56202i-033 Rubber Washer 1
34 56202i-034 Lock Nut 1
35 56202i-035 Fuel Tank Cap 1
36 56202i-036 Muffler Cover 1
37 56202i-037 O-Ring Seal 1
38 56202i-038 Retainer Ring 4
39 56202i-039
Self-Tapping Screw,
ST4.2 X 9.5
1
40 56202i-040 Spark Arrestor Assembly 1
41 56202i-041 Rear Air Guide 1
42 56202i-042 Oil Seal 1
43 56202i-043 Ignition Coil 1
44 56202i-044
Self-Tapping Screw,
ST4.8 X 20
2
45 56202i-045 Right Frame 1
46 56202i-046 Spark Plug Access Panel 1
47 56202i-047 Igniter 1
48 56202i-048 Right Cover Panel 1
49 56202i-049 Oil Access Panel 1
50 56202i-050 Screw, M6×12 1
51 56202i-051
Rectifier Bridge,
Capacitance
1
52 56202i-052 Damper Supports 4
53 56202i-053 Rubber Damper 1
54 56202i-054 Bottom Plate Assembly 1
55 56202i-055 Nut M6 4
56 56202i-056 Base 4
EXPLODED VIEW AND PARTS LIST
