No. Part No. Description Qty.
1 56202i-101
Hex Head Flange Bolt,
M6 × 18
4
2 56202i-102
Spark Plug, E5T (NKG
BP4H)
1
3 56202i-103 Breather Tube 1
4 56202i-104
Cylinder Head Cover
Assembly
1
5 56202i-105
Strainer, Cylinder Head
Cover
1
6 56202i-106
Inner Cover,
Cylinder Head Cover
1
7 56202i-107 Cross Screw, M3 × 6.5 3
8 56202i-108
Gasket, Cylinder Head
Cover
1
9 56202i-109 Rocker Arm Assembly 2
10 56202i-110 Shaft, Rocker Arm 1
11 56202i-111 Valve Collet 2
12 56202i-112 Oil Drip Plug 1
13 56202i-113 Valve Spring Seat, 182F 2
14 56202i-114 Spring Valve 2
15 56202i-115
Flange Bolt, M6 × 50,
GB5789
4
16 56202i-116 Cylinder Head 1
17 56202i-117 Stud Bolt, M6 × 72 2
18 56202i-118 Gasket, Muffler 1
19 56202i-119 Exhaust Muffler Assembly 1
20 56202i-120
Flange Bolt M6 × 60,
GB5789
4
21 56202i-121 Lock Nut M6, Flange 4
22 56202i-122 Stud Bolt, M6 × 87 2
23 56202i-123 Gasket, Carburetor 1
24 56202i-124 Insulator, Carburetor 1
25 56202i-125 Gasket, Insulator 1
26 56202i-126 Carburetor 1
27 56202i-127 Stepping Motor 1
28 56202i-128 Screw, M4 × 8 2
29 56202i-129 Clamp 1, Ø7.5 1
30 56202i-130 Oil Tube 1
31 56202i-131 Air Filter Hose 1
32 56202i-132 Clamp 1
33 56202i-133 Gasket, Cylinder Head 1
No. Part No. Description Qty.
34 56202i-134 Dowel Pin, Ø8 × 12 4
35 56202i-135 Push Rod 2
36 56202i-136 Valve, Exhaust 1
37 56202i-137 Valve, Intake 1
38 56202i-138 Lifter, Valve 2
39 56202i-139 Piston Ring Set 1
40 56202i-140 Circlip 2
41 56202i-141 Piston Pin 1
42 56202i-142 Piston 1
43 56202i-143 Connecting Rod Assembly 1
44 56202i-144 Crankcase 1
45 56202i-145 Oil Level Sensor 1
46 56202i-146
Hex Head Flange Bolt,
M6 × 16
2
47 56202i-147
Hex Head Flange Bolt,
M6 × 12
5
48 56202i-148 Crankshaft 1
49 56202i-149 Camshaft 1
50 56202i-150 Gasket, Crankcase Cover 1
51 56202i-151 Cover, Crankcase 1
52 56202i-152
Hex Head Flange Bolt,
M6 × 20
7
53 56202i-153 Oil Dipstick Assembly 1
54 56202i-154 Trigger 1
55 56202i-155 Oil Seal, Ø20 × Ø32 × 6 1
56 56202i-156
Alternator Assembly,
Ø150 × 44.5 mm
1
57 56202i-157 Flange Bolt, M6 × 32 2
58 56202i-158 Cooling Fan 1
59 56202i-159 Pulley, Starter 1
60 56202i-160 Flange Nut, M12 × 1.25 1
61 56202i-161 Fan Cover Assembly 1
62 56202i-162 Fan Cover 1
63 56202i-163 Air Filter Element 1
64 56202i-164 Air Filter Cover 1
65 56202i-165 Wire Clip B 1
66 56202i-166 Recoil Starter Assembly 1
67 56202i-167
Hex Head Flange Bolt,
M6 × 14
3
EXPLODED VIEW AND PARTS LIST
