Wen 56360i

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
12 56360iX-112 Bolt, M5x8 1
13 56360iX-113 Clamp 1
14 56360iX-114 Fuel Hose 1
15 56360iX-115 Clamp 3
16 56360iX-116 Fuel Filter 1
17 56360iX-117 Switch Assembly 1
18 56360iX-118 Clamp 1
19 56202i-030 Damping Pad 2
20 56360iX-120 Fuel Tank 1
21 56202i-033 Nut 1
22 56360iX-122 Fuel Cap 1
23 56360i-123 Left Hull Assembly 1
24 56202i-022 Alignment Bolt 6
25 56360iX-156 Fuel Hose Jacket 1
26 56360i-126
Left Cover Board
Assembly
1
27 56360iX-127 Phillips Bolt 2
28 56360iX-128 Screw,ST4.2x13 2
29 56360iX-129
Service Window
Assembly
1
30 56202i-038
Self-tappling Screw,
ST4.2x9.5
1
31 56202i-039 Spark Arrester 1
32 56360iX-132 O-Ring, Dipstick 1
GENERATOR
NO. PART NO. DESCRIPTION QTY.
33 56360i-133 Engine 1
34 56360iX-134 Carbon Canister 1
35 56360iX-135 Fuel Hose 1
36 56360iX-136 Fuel Hose 2
37 56360iX-137 Roll Over Valve 1
38 56360iX-138 Fuel Hose 1
39 56360iX-139 Fuel Tee Pipe 1
40 56360iX-140 Fuel Hose 1
41 56360iX-141 Roll Over Valve 1
42 56360iX-142 Fuel Hose 1
43 56360iX-143 Fuel Tee Pipe 1
44 56360i-144 Right Hull Assembly 1
45 56360i-145 Right Cover Assembly 1
46 56360iX-146 Shroud Cover 1
47 56360iX-147 Rectifier 1
48 56202i-053 Damping Pad 4
49 56202i-054 Damping Pad 1
50 56360iX-150 Switch Box Base 1
51 56360iX-151 Switch Box Base Body 1
52 56202i-020
Fuel Tank Mount Thread
Tab
4
53 56202i-056 Nut, M6 4
54 56360iX-154 Rubber Cap 4
