SPECIFICATIONS
Model Number 56477i
Surge (Starting) Wattage 4800W
Rated (Running) Wattage 4000W
Rated Voltage AC: 120V; DC: 12V / 5V
Rated Amperage AC 33.3A; DC 8.3A (12V), 2.1A / 1A (USB)
Phase Single
Frequency 60 Hz
Product Weight 72.7 Pounds
Product Dimensions 23.8 in. x 12.6 in. x 22.1 in.
GENERATOR
Engine Type 4 Stroke, OHV, Single Cylinder with Forced Air Cooling System
Engine Displacement 224cc
Engine Speed 3600 RPM
Fuel Tank Capacity 1.9 gallons (7.20 L)
Oil Capacity 20.3 fl. oz. (0.60 L)
Half-Load Run Time 7 hours
Spark Plug Type F6RTC (NGK BPR6ES)
Spark Plug Gap 0.028 in. - 0.031 in. (0.7mm - 0.8mm)
Spark Plug Torque 11 - 14.5 ft-lbs (15 - 20 Nm)
ENGINE
