Wen 56477i User Manual

EXPLODED VIEW & PARTS LIST
GENERATOR
32
NO. PART NO. DESCRIPTION QTY.
1 56477i-001 Handle Assembly 1
2 56360iX-122 Fuel Tank Cap 1
3 56202i-033 Fuel Tank Nut 1
4 56477i-004 Top Cover 1
5 56477i-005 Handle Cover 1
6 56477i-006 Rear Cover 1
7 56477i-007 Left Front Service Panel 1
8 56477i-008 Left Rear Service Panel 1
9 56477i-009 Left Housing 1
10 56477i-010 Cylinder Head Cover 1
11 56477i-011 Base 1
12 56477i-012
Control Panel
Assembly
1
13 56477i-013 Front Cover 1
14 56477i-014 Right Housing 1
15 56477i-015 Battery Cover Panel 1
16 56477i-016 Phillips Bolt, M5x10.7 1
17 56477i-017 Muffler Panel 1
18 56477i-018 Bolt, M8x12 2
19 56477i-019 Wheel 2
20 56477i-020 Axle Assembly 1
21 56477i-021 Fuel Tank 1
22 56477i-022 Bolt, M8x25 2
23 56477i-023 Washer, 4mm 5
24 56477i-024 Bushing 1
25 56477i-025 Phillips Screw, M5x12 44
26 56477i-026 Clip 1
27 56477i-027 Clamp 1
28 56477i-028 Engine Mount 1 2
29 56477i-029 Engine Mount 2 1
30 56477i-030 Engine Mount 3 1
31 56477i-031 Engine Assembly 1
32 56477i-032
Inverter Mounting
Bracket
1
33 56477i-033 Inverter 1
34 56477i-034 Retaining Ring, 4mm 1
NO. PART NO. DESCRIPTION QTY.
35 56477i-035 Bolt, M6x22 6
36 56202i-051 Bolt, M6x12 2
37 56360iX-108 Wiring Sheath, 25mm 1
38 56477i-038 Fuel Pump 1
39 56477i-039
Self-tapping Screw,
ST3.5x13
5
40 56477i-040
Combination Fuel Valve
and Engine Switch
1
41 56477i-041 Recoil Starter Shield 1
42 56477i-042 Muffler Panel Gasket 1
43 56202i-001 Screw, M4x10 7
44 56477i-044 Bottom Bracket 2 1
45 56202i-013 Bolt, M6x12 3
46 56477i-046 Foot 2
47 56477i-047 Bottom Bracket 1 1
48 56477i-048 Igniter 1
49 56477i-049 Grounding Wire 1
50 56477i-050 Clip 4
51 56477i-051 Wiring Harness 1
52 56477i-052ASM Rear Cover Assembly 1
53 56477i-053 Fuel Hose 1
54 56477i-054 Fuel Tank Bumper 2
55 56477i-055 Fuel Filter 1
56 56477i-056 Handle Plug 2
57 56477i-057 Fuel Hose 1
58 56477i-058 Carbon Tank 1
59 56477i-059 Fuel Hose 1
60 56477i-060
Wiring Sheath with
Notch
2
61 56477i-061 Phillips Bolt, M6x5.5 6
62 56477i-062 Nut, M8 6
63 56477i-063 Fuel Hose 1
64 56477i-064 Carbon Tank Tube 1
65 56477i-065 Wiring Clamp 2
66 56477i-066ASM
Right Housing
Assembly
1
