Wen 6033 User Manual

EXPLODED VIEW AND PARTS LIST
No. Part No. Description Qty.
1 6033-001 Depth Adjusting Dial 1
2 6033-002 Fine Adjustment Rod 1
3 6033-003 Fine Adjustment Dial 1
4 6033-004 Depth Set Pole 1
5 6033-005 Screw ST4 X 20mm 6
6 6033-006 Motor End Cap 1
7 6033-007 Carbon Brush Cap 2
8 6033-008 Carbon Brush 2
9 6033-009 Carbon Brush Holder 2
10 6033-010 Motor Housing 1
11 6033-011 Bolt M4 X 90mm 4
12 6033-012 Washer 4 4
13 6033-013 Screw ST4 X 16mm 9
14 6033-014 Side Cap 1
15 6033-015 Speeder 1
16 6033-016 Motor Field 1
17 6033-017 Bearing 629 1
18 6033-018 Bolt 5 X 70mm 2
19 6033-019 Armature 1
20 6033-020 Sunk Bolt M4 X 8mm 4
21 6033-021 Bearing Holding Plate 1
22 6033-022 Bearing 6004 1
23 6033-023 Wind Ring 1
24 6033-024 Motor Base 1
25 6033-025 Left Handle Cover 1
26 6033-026 Bolt M5 X 16mm 4
27 6033-027 Left Handle Housing 1
28 6033-028 Bolt M4 X 12mm 1
29 6033-029 Depth Lock Lever 1
30 6033-030 Depth Lock Shaft 1
31 6033-031 Depth Lock Spring 1
32 6033-032 Sleeve 1
33 6033-033 Knob Spring 6
34 6033-034 16mm Knob 6
35 6033-035 Spindle Lock Button 1
36 6033-036 Button Spring 1
37 6033-037 Thread Plate 1
38 6033-038 10mm Knob 1
39 6033-039 1/4" Shank Adapter 1
40 6033-040 Spindle Flange 1
No Part No. Number Qty.
41 6033-041 Bolt M6 X 20mm 2
42 6033-042 1/2" Collet & Nut Assembly 1
43 6033-043 Position Rod 2
44 6033-044 Guide Rod Spring - Long 1
45 6033-045 Buffer Sleeve 2
46 6033-046 Guide Rod - Long 1
47 6033-047 Bolt M5 X 12mm 1
48 6033-048 Depth Set Block 1
49 6033-049 Steel Ball 1
50 6033-050 Steel Ball Spring 1
51 6033-051 Power Cord 1
52 6033-052 Power Cord Strain Relief 1
53 6033-053 Lock-On Switch 1
54 6033-054 Right Handle Housing 1
55 6033-055 Cord Clamp 1
56 6033-056 Right Handle Cover 1
57 6033-057 Capacitor 0.33U 1
58 6033-058 Inducer 1
59 6033-059 Guide Rod Spring - Short 1
60 6033-060 Circlip 1
61 6033-061 Guide Rod - Short 1
62 6033-062 Router Base 1
63 6033-063 Thread Post M6 X 14mm 2
64 6033-064 Base Plate 1
65 6033-065 Template Guide 1
66 6033-066 Wrench 1
67 6033-067 Centering Pin 1
68 6033-068 Fence Pole 2
69 6033-069 Bolt M6 X 8mm 4
70 6033-070 Fence Sliding Pad 2
71 6033-071 Straight Fence Bracket 1
72 6033-072 Dust Extraction Duct 1
73 6033-073 Sunk Bolt M4 X 25mm 2
74 6033-074 Fence Pole Scale 1
75 6033-075 Profile Guide 1
76 6033-076 Sunk Bolt M5 X 10mm 4
77 6033-077 Nut M4 2
78 6033-078 Screw ST4 X 12mm 2
79 6033-079 Depth Lock Insert 1
80 6033-080 Spring 2
