7. Variable Speed Dial
8. Router Handle &
Power Switch
2. Depth Stop Pole
3. Depth Adjustment Dial
4. Height Lock Lever
5. Depth Lock Knob
6. Depth Stop Turret
Straight Guide Fence
Fence Pole
Centring Pin
1/4" Router Bit
Shank Adaptor
Profile Guide
9. Spindle Lock Button
10. 1/2" Collet & Nut
Assembly
11. Router Base
Dust Collection Duct
Template Guide
Wrench
Fence Pole Scale
ACCESSORIES
ROUTER
7
KNOW YOUR ELECTRIC ROUTER
Use the diagram below to become familiarized with all the controls and accessories of your electric router. Refer to
the next page for explanations of each control. Make sure to account for all the parts and accessories. If any part is
damaged or missing, please contact our Customer Service at (800) 232-1195, M-F 8-5 CST.
1. Fine-Tune Adjustment Dial
To Next Page
