7
AMPERAGE
REQUIRED GAUGE FOR EXTENSION CORDS
25 ft. 50 ft. 100 ft. 150 ft.
7 A 18 gauge 16 gauge 14 gauge 12 gauge
KNOW YOUR SANDER
ASSEMBLY AND ADJUSTMENTS
REMOVING OR INSTALLING ABRASIVE BELT
WARNING: To avoid injury from accidental startups, turn switch OFF and remove the plug from the
power source outlet before making any adjustments.
1. Turn the tool upside down and pull the tension lever (4) to retract the
front roller and release the belt tension.
2. Slide the abrasive belt (6) off.
3. Mount a new abrasive belt.
CAUTION: Be sure that the arrow on the inside of the belt is pointing the
same direction as that of the tool.
4. Push the tension lever down to the original position.
CAUTION: Ensure that your fingers are not trapped while adding tension
back to the sander.
ON/OFF SWITCH
TENSION LEVER
DUST PORT
TRACKING KNOB
