No. Part No. Description Qty.
1 6362-001 Hex Screw M6x14 1
2 6362-002 M6 Spring 1
3 6362-003 M6 Stop Button 1
4 6369-003 Sanding Pad 1
5 6362-005 Dust Seal 1
6 6362-006 Output Shaft 1
7 6362-007
Collar Φ22
1
8 6362-008 Bearing 6900 Rs 1
9 6362-009 End Cover 1
10 6362-010 Screw ST3.9x16 6
11 6362-011 Paper Washer 1
12 6362-012 Big Gear 1
13 6362-013 Spring 4
14 6362-014 Clamp Plate 1
15 6362-015 Base Pad Guard 1
16 6362-016 Compression Spring 1
17 6362-017 Brush Segment 1
18 6362-018 Screw ST3×8 1
19 6362-019 Wavy Sleeve 1
20 6362-020
Ball Φ4
1
21 6362-021 Dial Spring 1
22 6362-022 Dust Extraction Dial 1
23 6362-023
Flat Washer Φ4
1
24 6362-024 Screw ST3.9×10 1
25 6362-025 Rotor Spring 1
26 6362-026 Wool Washer 1
27 6362-027 Bearing 608RS 1
28 6362-028
Flat Washer Φ8
1
29 6362-029 Rotor 1
30 6362-030 Stator 1
31 6362-031 Magnet Ring 1
32 6362-032
Flat Washer Φ7
1
33 6362-033 Bearing 607Rs 1
34 6362-034 Speed Regulator 1
EXPLODED VIEW & PARTS LIST
15
No. Part No. Description Qty.
35 6362-035
Pin Φ3x16
1
36 6362-036
Seal Belt Φ1.2
1
37 6362-037 Bearing 606Z 1
38 6362-038 Tension Spring 2
39 6362-039 Brush Holder 2
40 6362-040 Carbon Brush 2
41 6362-041 Brush Holder Cover 2
42 6362-042 Switch 1
43 6362-043 Ventilation Board 1
44 6362-044 Housing 1
45 6362-045 Cord Clamp 1
46 6362-046 Screw ST3.9×14 8
47 6362-047 Screw ST3×10 1
48 6362-048 Screw ST3.9×16 9
49 6362-049 Power Cord & Plug 1
50 6362-050 Cord Sleeve 1
51 6362-051 Handle 1
52 6362-052 Dust Bag 1
53 6362-053 Dust Hose 1
54 6362-054
Middle Connector
(for No. 55 & 56)
3
55 6362-055
57mm Adapter
(One as accessory and
one inside dust bag)
2
56 6369-102 47mm Adapter 1
57 6362-057 Dust Port Connector 1
58 6362-058 Hex Wrench M5 1
59 6362-059 Shoulder Strap 1
The sanding discs below are not pictured.
Sanding discs are compatible with WEN 6369.
60 6369SP150 150-Grit Sanding Disc 2
61 6369SP180 180-Grit Sanding Disc 2
62 6369SP240 240-Grit Sanding Disc 2
63 6369SP400 400-Grit Sanding Disc 2
To Next Page
