EXPLODED VIEW AND PARTS LIST
Part# Stock # Description Part# Stock # Description
1
90225001
Hex nut 10 42
90225042
Bearing Cover
2
90225002
Upper spindle washer 43
90225043
Felt
3
90225003
Sander sleeve 44
90225044
Rubber washer
4
90225004
Rubber spindle 45
90225045
Bearing 6203zz
5
90225005
Throat plate 46
90225046
Bearing support
6
90225006
Lower spindle washer 47
90225047
Screw 4.2x15
7
90225007
Cast iron table 48
90225048
Bearing sleeve
8
90225008
Dust washer 49
90225049
Spring
9
90225009
Dust cover 50
90225050
Spring washer
10
90225010
Washer 5 51
90225051
Spindle washer
11
90225011
Spring washer 5 52
90225052
Screw 4.2x13
12
90225012
Screw 5x12 53
90225053
Wheel plate
13
90225013
Belt 54
90225054
Wheel(Ⅰ)
14
90225014
Belt Ⅱ 55
90225055
Spindle
15
90225015
Belt wheel 56
90225056
Pin
16
90225016
Spring washer 57
90225057
Wheel(Ⅱ)
17
90225017
Tension roller assembly 58
90225058
Bearing sleeve
18
90225018
Screw 4.2x13 59
90225059
Wheel plate
19
90225019
Orientation plate assembly 60
90225060
Screw 4.2x13
20
90225020
Screw 4.2x22 61
90225061
Screw 4.2x13
21
90225021
Washer 6 62
90225062
Bearing support
22
90225022
Spring washer 6 63
90225063
Bearing 6203zz
23
90225023
Screw 6x16 64
90225064
Rubber washer
24
90225024
Cord clamp 65
90225065
Felt
25
90225025
Screw 4.2x15 66
90225066
Wheel support
26
90225026
Bearing 6001zz 67
90225067
Wire assembly(Ⅰ)
27
90225027
Spring washer 68
90225068
Wire assembly(Ⅱ)
28
90225028
Armature assembly 69
90225069
Rectifier
29
90225029
Bearing 608zz 70
90225070
Screw 4.2x19
30
90225030
Connection plate 71
90225071
Wire assembly(Ⅲ)
31
90225031
Field assembly 72
90225072
Wire assembly(Ⅳ)
32
90225032
Rear cover 73
90225073
Power cord
33
90225033
Brush holder 74
90225074
Cord clamp
34
90225034
Carbon brush 75
90225075
Switch orientation plate
35
90225035
Brush spring 76
90225076
Housing base
36
90225036
Cord clamp 78
90225078
Logo label
37
90225037
Washer 4 79
90225079
Switch orientation(Ⅰ)
38
90225038
Screw 4.2x13 80
90225080
Switch
39
90225039
Washer 4 81
90225081
Switch orientation(Ⅱ)
40
90225040
Screw 4.2x110 82
90225082
Switch assistant orientation
41
90225041
Screw 4.2x22 83
90225083
Screw 4x16
