Wen 6510 - Page 15

EXPLODED VIEW AND PARTS LIST
Part# Stock # Description Part# Stock # Description
84
90225084
Warning label(Ⅰ) 100
90225100
2”Throat plate
85
90225085
Cord clamp 101
90225101
3” Throat plate
86
90225086
Screw 4.2x15 102
90225102
1/2”Sanding sleeve(80 grit)
87
90225087
Thread 103
90225103
3/4” Sanding sleeve(80 grit)
88
90225088
Screw 4.2x10 104
90225104
1” Sanding sleeve(80 grit)
89
90225089
Rubber foot 105
90225105
1-1/2” Sanding sleeve(80 grit)
90
90225090
Washer 6 106
90225106
2” Sanding sleeve(80 grit)
91
90225091
Spring washer 6 107
90225107
3” Sanding sleeve(80 grit)
92
90225092
Screw 6x16 108
90225108
3/4”Rubber spindle
93
90225093
Bottom plate 109
90225109
1” Rubber spindle
94
90225094
Screw 4.2x13 110
90225110
1-1/2” Rubber spindle
95
90225095
Warning label(Ⅱ) 111
90225111
2” Rubber spindle
96
90225096
1/2”Throat plate 112
90225112
3” Rubber spindle
97
90225097
3/4”Throat plate 113
90225113
5/8”OD Rubber spindle
98
90225098
1” Throat plate 114
90225114
7/8” OD Rubber spindle
99
90225099
1-1/2” Throat plate 115
90225115
1-3/4” OD Rubber spindle
