KNOW YOUR HAND PLANER
TOOL PURPOSE
The power to trim doors, flatten boards, and much more is in the palm of your hand with your WEN Hand Planer.
Refer to the following diagrams to become familiarized with all the parts and controls of your hand planer. The com-
ponents will be referred to later in the manual for assembly and operation instructions.
Chip Extraction Port
Front Handle
Power Cord
Trigger Lock
ON /OFF Switch
Rear Handle
Chip Extraction Switch
Fixed Rear Shoe
Chip Extraction Port
Drive Belt Cover
Parallel Guide Lock Knob
Adjustable Front Shoe
Depth Gauge
Depth Adjustment Knob
Dust Port Parallel Guide FenceBlade Wrench
