Wen 6552T User Manual

EXPLODED VIEW & PARTS LIST
19
No. Part No. Description Qty
1
6550-105
Handle Assembly 1
2 Cap 1
3 Socket Head Screw 1
4 Flat Washer 1
5 6552-005 Roller 2
6 6552-006 Roller Cap 4
7 6552-007 Flat Head Screw 4
8 6552-008 Top Cover 1
9 6552-009 Grip 2
10 6552-010 Flat Head Screw 4
11 6552-011 Left Cover 2
12 6552-012 Retaining Ring 3
13 6550-215 Chain 2
14 6550-216 Sprocket 4
15 6552-015 Socket Head Screw 4
16 6550-217 Spacer 1
17 6550-219 Gear Box Assembly 1
18 6550-220 Pinion 1
19 6550-221 Ball Bearing 1
20 6550-139 Elevating Nut (LH) 2
21 6550-233 Set Screw 4
22 6552-022 Cable Clamp 1
23 6550-228 Socket Head Screw 1
24 6552-024 Chain Cover 1
25 6552-025 Pan Head Screw 2
26 6552-026 Lock Washer 2
27 6552-027 Serrated Washer 2
28 6552-028 Socket Head Screw 2
29 6552-029 Belt Cover 1
30 6550-108 Elevating Nut (RH) 2
31 6552-031B Pan Head Screw, M5 2
32 6550-259B
Depth Indicator, M5
Holes
1
33 6552-033C Rollercase 1
34 6552-034B Motor Pivot Rod 1
35 6552-035 Rod Clamp 2
36 6552-036 Set Screw 2
37 6552-037 Lock Washer 4
38 6552-038 Pan Head Screw 4
39 6552-039 Depth-Of-Cut Gauge 1
40 6552-040 Pan Head Screw 3
41 6552-041 Cutterhead 1
42 6552-042 Key 1
No. Part No. Description Qty
43 6552-043 Blade 3
44 6552-044 Blade Clamp 3
45 6552-045 Socket Head Screw 16
46 6552-046 Ball Bearing 1
47 6550-250 Bearing House 1
48 6552-048 Pan Head Screw 3
49 6552-049 Cutterhead Pulley 1
50 6552-050 Motor Pulley 1
51 6550-246 Belt 1
52 6550-245 Hex Nut 1
53 6550-202 Screw 2
54 6550-201 Dust Exhaust Port 1
55 6552-055 Connecting Port 1
56 6552-056 Socket Head Screw 4
57 6552-057 Flat Washer 4
58 6552-058 Dust Chute 1
59 6552-059 Chute Plate 1
60 6552-060 Flat Head Tap Screw 4
61 6550-137 Hex Wrench 1
62 6550-138 Magnet 2
63 6552-063 Spring 4
64 6550-252 Bearing Block 4
65 6550-257 LH Retainer 2
66 6552-066 Flat Washer 8
67 6552-067 Lock Washer 8
68 6552-068 Socket Head Screw 8
69 6552-069 Outfeed Roller 1
70 6552-070 Rh Retainer 2
71 6552-071 Infeed Roller 1
72 6552-072 Power Cord 1
73 6552-073B Motor 1
74 6550-210 Switch 1
75 6550-260 Circuit Breaker 1
76 6550-211 Brush Holder 2
77 6550-212 Brush 2
78 6550-213 Brush Cap 2
79 6552-079 Spacer 1
80 6552-080 Flat Washer 1
81 6552-081 Socket Head Screw 1
82 6552-082 Socket Head Screw 1
83 6552-083 Flat Washer 1
84 6550-112 Elevating Screw (LH) 1
85 6552-085B Flat Washer 2
No. Part No. Description Qty
86 6552-086B Ball Bearing 2
87 6552-087B Bearing Retainer Plate 2
88 6552-088B Socket Pan Head Screw 4
89 6552-089B Flat Washer 2
90 6552-090B Column 4
91 6552-091B Socket Head Screw 4
92 6552-092 Guide 2
93 6552-093 Table 1
94 6552-094 Socket Head Screw 8
95 6552-095 Flat Washer 8
96 6552-096
Outfeed Extension Table
Assembly
1
97 6552-097 Flat Washer 12
98 6552-098 Lock Washer 12
99 6552-099 Socket Pan Head Screw 12
100 6550-117 Elevating Screw (RH) 1
104 6552-104B Base 1
105 6552-105 Infeed Extension Table 1
106 6550-129 Bushing 4
107 6550-130 Wavy Washer 4
108 6552-108 Table Support 4
109 6552-109 Lock Washer 4
110 6552-110 Socket Head Screw 4
111 6552-111 Extension Table 2
112 6552-112 Hex Head Bolt 4
113 6552-113 Hex Nut 4
114 6550-134 Bevel Gear 4
115 6552-115B Socket Head Screw 2
116 6550-131 Shaft 1
117 6552-117B Flat Washer 2
118 6550-132 Support 2
119 6552-119 Socket Head Screw 4
120 6552-120 Retaining Ring 2
121 6552-121 Plunger 1
122 6552-122 Spring 1
123 6552-123 Cutterhead Lock Latch 1
124 6552-124 Washer 1
125 6552-125 Socket Head Screw 1
126 6552-126B Flat Washer 4
