Wen DF1100X User Manual

EXPLODED VIEW & PARTS LIST
GENERATOR
No. Part No. Description Qty.
1 DF1100X-001 Alternator Assembly 1
1.1 DF475-001.1
Carbon Brush
Assembly
1
2 DF1100-002 Motor Stand 1
3 DF1100-003 Bolt M5×230 2
4 DF1100-004 Nut M5 2
5 DF475X-066 CO Sensor Module 1
6 DF1100-006 Spring Washer, 5mm 2
7 DF1100X-007 Frame 1
8 DF1100-008 Rack Cable 1
9 DF1100-009 Isolator B 4
10 DF475-010 Fuel Filter 1
11 DF1100X-011 Fuel Tank Assembly 1
12 DF475-012 Fuel Cock 1
13 DF1100X-013 Regulator Assembly 1
14 DF475X-014 Regulator 1
15 DF1100-015 Crankcase Cover 1
16 DF1100-016 Flat Washer 2
17 DF1100-017 Bolt, M10x283 1
18 DF475-016 Rotor Bolt Gasket 1
19 DF1100X-019 Handle Assembly 2
20 DF1100-020 Bolt, M6×195 4
21 DF1100-021 Bolt, M6X12 11
22 DF1100-022 Nut, M10 4
23 DF1100-023 Air Filter Bracket 1
24 DF1100-024 Exhaust Pipe Gasket 1
25 DF1100-025 Cotter Pin 2
26 DF1100X-026 Muffler Assembly 1
27 DF1100-027 Spring Washer 2
28 DF1100-028 Bolt, M8X30 2
29 DF1100X-029 Panel Assembly 1
29.1 DF475-029.1 Ignition Switch 1
N.P. P55340 Starter Key (set of 2) 1
No. Part No. Description Qty.
29.2 DF1100-029.4 Multi-Meter 1
29.3 DF475-029.2 12V DC Receptacle 1
29.4 DF1100-029.9 DC Breaker, 8A 1
29.5 DF1100-029.3 AC Breaker, 20A 2
29.6 DF1100X-029.6
NEMA 5-20R 120V
20A GFCI Duplex
Outlet
2
29.7 DF1100-029.10 AC Breaker, 30A 1
29.8 DF1100-029.7
NEMA L5-30R 120V
30A Outlet
1
29.9 DF1100-029.8
NEMA 14-50R
120V/240V 50A Outlet
1
29.10 DF1100-029.6 AC Breaker, 35A 2
29.11 DF1100X-029.11 Grounding Lug 1
29.12 DF1100-029.11 Charger 1
29.13 DF475-029.10 Rectifier 1
30 DF1100-030 Handle Plug 2
31 DF1100-031 Bolt, M8x45 2
32 DF1100-032 Bolt, M6x25 2
33 DF1100-033
Automatic Voltage
Regulator
1
34 DF475-034 Bolt, M5x16 3
35 DF475-035 Bolt, M5x12 6
36 DF475X-036
CO Sensor Engine
Controller
1
37 DF475X-037 Bolt, M6x25 4
38 DF1100-038 Generator End Cover 1
39 DF475-039 Positive Lead 1
40 DF1100-040 Negative Lead 1
41 DF1100-041 Battery, 12V 14Ah 1
42 DF1100-042 Wheel 2
43 DF1100-043
Foot Support
Assembly
2
44 DF1100-044 Vibration Isolation Pad 2
45 DF475-045 Nut, M6 6
38
