EXPLODED VIEW & PARTS LIST
GENERATOR
No. Part No. Description Qty.
46 DF475-046 Bolt, M8x16 4
47 DF475-047 Clip, 12mm 2
48 DF1100-048 Wheel Axle 2
49 DF1100X-049 Screw Stud, M4x28 2
50 DF1100-050 Muffler Bracket 1
51 DF1100-051 Tie Wrap 1
52 DF475-063 Fuel Line Clip, 10mm 1
53 DF1100-053 Low Pressure Pipe 1
54 DF1100X-054 Nut, M10 2
55 DF1100X-055 Fuel Line (Fuel Cock) 1
56 DF1100X-056 Fuel Line 1
57 DF1100-057
Connecting Pipe (Gas
Tank)
1
58 DF1100-058
Manual Choke
Assembly
1
59 DF475-003 Fuel Selector Switch 1
60 DF475-060 Fuel Line Clip, 7.5mm 1
61 DF1100X-061 Fuel Line Clip, 9.5mm 5
62 DF1100-062
Dustproof Sheet,
Right
1
63 DF475-004
Hex Head Screw,
M6x12
1
No. Part No. Description Qty.
64 DF475-064 Nut, M6 10
65 DF475-073 Fuel Tank Cap 1
66 DF475-022 Nut, M5 3
67 DF1100-067 Handle Bushing 4
68 DF1100-062 Dustproof Sheet (Left) 1
69 DF1100X-069 Fuel Selector Switch 1
70 DF1100-079 Connecting Pipe 1
71 DF1100X-071 Fuel Line Clip, 8.5mm 1
72 DF475-072 Paper Washer 5
73 DF1100-073 Handle Rubber Cover 2
74 DF1100-074 Grounding Wire 1
75 DF1100X-075 Carbon Tank Assembly 1
76 DF475-074 LPG Regulator Cover 1
77 DF1100X-077 Isolator 1
78 DF1100X-078 Fuel Line Clip, 9mm 1
79 DF1100X-079 Engine Assembly 1
80 DF1100-080 Fuel Gauge 1
81 DF1100-081 Fuel Tank Filter 1
39
