EXPLODED VIEW & PARTS LIST
ENGINE
No. Part No. Description Qty.
1 DF1100-101 Crankcase 1
2 DF1100-102 Ball Bearing 2
3 DF1100X-103 Oil Seal 2
4 DF1100-104
Governor Arm Shaft
Seal
1
5 DF1100-105 Governor Arm Shaft 1
6 DF1100-106
Governor Arm Shaft
Washer
1
7 DF1100-107 Lock Pin 1
8 DF1100-108 Drain Bolt 1
9 DF1100-109 Drain Bolt Washer 1
10 DF1100-110
Oil Level Switch
Assembly
1
11 DF1100-111 Bolt, M6x16 2
12 DF1100X-112
Crankcase Cover
Dowel Pin
2
13 DF1100-113 Piston 1
14 DF1100-114
Piston Scraper Ring
Set
1
15 DF1100-115
Connecting Rod
Assembly
1
16 DF1100-116 Piston Pin 1
17 DF1100-117 Piston Pin Clip 2
18 DF1100-118
Crankcase Cover
Assembly
1
19 DF1100-102 Ball Bearing 1
20 DF1100-120 Governor Assembly 1
21 DF1100X-021 Cylinder Head 1
22 DF1100-122 Intake Valve 1
23 DF1100-123 Exhaust Valve 1
24 DF1100-124 Intake Valve Returner 2
25 DF1100-125 Valve Oil Seal 2
26 DF1100-126 Valve Spring 2
27 DF1100X-027 Fuel Line (Carburetor) 1
No. Part No. Description Qty.
28 DF1100-128
Exhaust Valve Spring
Seat
2
29 DF1100-129 Push Rod Guide Plate 1
30 DF1100-130 Rocker Assembly 2
31 DF1100-131 Rotator 2
32 DF1100-132 Stud Bolt (Carburetor) 2
33 DF1100-133 Stud Bolt (Exhaust) 2
34 DF1100-134 Exhaust Gasket 1
35 DF1100-135 Dipstick 1
36 DF1100-136 Spring Washer 2
37 DF1100-137 Nut M8 2
38 DF1100-138 Carburetor Assembly 1
39 DF1100-139 Governor Arm 1
40 DF1100X-140 Fuel Line Sleeve 1
41 DF1100-141 Nut, M6 2
42 DF1100X-142 Crankshaft Assembly 1
43 DF1100-143 Valve Lifter 2
44 DF1100-144
Crankcase Cover
Gasket
1
45 DF1100-145 Balancing Shaft 1
46 DF1100-146 Camshaft Assembly 1
47 DF1100-147 Bolt M8x35 2
48 DF1100-148 Bolt M8x40 7
49 DF1100-149 Dowel Pin 2
50 DF1100-150 Cylinder Head Gasket 1
51 DF1100-151 Bolt M10x80 4
52 DF475-145
Spark Plug (Torch
F7TC / NGK BP7ES)
1
53 DF1100-153 Push Rod 2
54 DF1100-154 Shroud 1
55 DF1100-155 Bolt M6x12 9
56 DF1100-156
Cylinder Head Cover
Assembly
1
41
