Wen DF1100X User Manual

EXPLODED VIEW & PARTS LIST
ENGINE
No. Part No. Description Qty.
57 DF1100-157
Cylinder Head Cover
Gasket
1
58 DF1100-158 Lock Bolt 1
59 DF1100-159
Upper Shroud
Assembly
1
60 DF1100-160 Flywheel Assembly 1
61 DF1100-161 Recoil Starter Fan 1
62 DF1100-162 Starter Pulley 1
63 DF1100-163 Flywheel Nut, M16-1.5 1
64 DF1100-164
Rubber Starter
Assembly
1
65 DF1100-165 Ignition Coil Assembly 1
66 DF1100-166 Bolt M6x25 2
67 DF1100-167 Intake Gasket 1
68 DF1100-168 Carburetor Insulator 1
69 DF1100-169 Carburetor Gasket 1
70 DF1100-170 Adjuster Rocker Arm 2
71 DF1100-171 Exhaust Pipe 1
72 DF1100-172 Governor Rod 1
No. Part No. Description Qty.
73 DF1100-173 Throttle Return Spring 1
74 DF1100X-174
Recoil Starter
Assembly
1
74.1 DF1100X-174.1 Recoil Starter 1
75 DF1100-175 Air Cleaner Assembly 1
75.1 DF1100-175.1 Air Filter Element 1
76 DF1100-176 Breather Tube 1
77 DF1100-177 Governor Spring 1
78 DF1100-178 Valve Locking Clips 4
79 DF1100-179 Clip 2
80 DF1100-183
Starter Motor
Assembly
1
81 DF1100-181 Air Filter Gasket 1
82 DF1100-182 Fuel Line Clip 1
83 DF1100X-183
Low Pressure Hose
Clip
1
84 DF1100X-184 Low Pressure Hose 1
85 DF1100X-185 Wiring Harness Clip 1
42
