Wen DF430X User Manual

EXPLODED VIEW & PARTS LIST
GENERATOR
No. Part No. Description Qty.
1
56500-001 Handrail Jacket 2
2 DF430X-002 Push Handle 2
3 GN6000-003 Nut M8 2
4 56500-001 Handrail Plug 2
5 GN6000-005 Bolt, M8x40 2
6 DF430X-006 Frame Assembly 1
7 56500-007 Circlip 2
9 DF430X-009 Tire 2
10 DF430X-010 Wheel Shaft 2
11 56500-010 Damping Pad 3
12 56500-011 Clamp 1
13 DF430X-013 Fuel Switch 1
14 DF430X-014 Fuel Tank 1
15 DF430X-015 Bolt, M6x14 4
16 DF430X-016 Bolt, M6x16 2
17 56500-016
Washer,
ɸ6.5x2xɸ25
4
18 56500-017 Bolt, M6×25 4
19 56500-018 Fuel Cap 1
20 56500-019 Oily Sense Clip 1
21 DF430X-021 Engine 1
22 DF430X-022 Gasket, Muffler 1
23 DF430X-023 Muffler 1
24 56500-025 Nut, M8 2
25 56500-026 Bolt, M8x16 2
26 56500-027 Bolt, M5x14 5
27 DF430X-027 End Cover 1
28 56500-029 Bolt, M5x18 3
29 56500-030 Voltage Regulator 1
30 DF430X-030 Brush 1
31 56500-032
Washer, ɸ5
1
32 56500-033
Washer, ɸ5
1
33 DF430X-033 Bolt, M6x165 4
No. Part No. Description Qty.
34 DF430X-034 Rear Bracket 1
35 56500-036 Nut, M8 8
36 56500-037 Earth Wire 1
37 GN6000-038 Damping Pad 2
38 56500-1038
Washer, ɸ6
1
39 GN6000-039 Damping Pad 2
40 DF430X-040 Bolt, M8x1x220 1
41 GN9500-033
Washer, ɸ8
1
42 DF430X-042
Washer, ɸ8
1
43 DF430X-043 Alternator 1
44 DF430X-044
Gas pressure
reducing valve
1
45 DF430X-045
Gas Pressure
Reducing Valve
1
46 DF430X-046 Valve 1
47 56500-1047 Bolt, M6x12 4
48 56500-044 Nut, M6 3
49 DF430X-049 Switch 1
50 DF430X-050 Control Panel 1
51 56500-047 Clamp 3
52 56500-052 Clamp 3
53 56500-049 Carbon Canister 1
54 DF430X-054
Tube, Carbon
Canister
1
55 56500-051
Tube, Carbon
Canister
1
56 DF430X-056 Clamp 1
57 DF430X-057 Support Base 1
58 DF430X-058 Support Base 1
59 DF430X-059 Damping Pad 2
60 DF430X-060 Bolt, M6x18 2
61 56500-060 Bolt, M8x16 2
62 56500-055 Bush 2
63 DF430X-063 Washer 4
36
