EXPLODED VIEW & PARTS LIST
ENGINE
No. Part No. Description Qty.
1 GN9500-101 Bolt, M6x16 6
2 DF430X-076 Valve Cover 1
3 DF430X-077 Breather Hose 1
4 DF430X-078 Gasket, Valve Cover 1
5 DF430X-079
Rocker Arm
Assembly
2
6 DF430X-080 Rocker Arm Base 1
7 GN9500-184 Bolt, M6x10 2
8 DF430X-081 Shroud 1
9 DF430X-082 Valve Locker 4
10 56500-114 Valve Spring Seat 2
11 DF430X-083 Valve Spring 2
12 56500-116 Intake Valve Seal 1
13 DF430X-084 Bolt, M8x60 4
14 DF430X-085 Cylinder Head 1
15 GN9500-116 Stud, M8x35 2
16 DF430X-086 Spark Plug 1
17 DF430X-087 Stud, M6x96 2
18 DF430X-088
Gasket, Carburetor
Insulator
1
19 DF430X-089 Insulator 1
20 DF430X-090 Gasket, Carburetor 1
21 DF430X-091 Carburetor 1
22 DF430X-092
Fuel Hose,
ɸ4xɸ8x175
1
23 56500-177 Clamp 1
24 DF430X-093 Gasket, Carburetor 1
25 DF430X-094 Air Filter Assembly 1
26 DF430X-095
Air Filter Base
Assembly
1
27 56500-133 Air Filter Baffle 1
28 56500-134 Air Filter Element 1
29 DF430X-096 Air Filter Cover 1
30 56500-136 Bolt 1
No. Part No. Description Qty.
31 GN9500-140 Nut, M6 2
32 DF430X-097
Gasket, Cylinder
Head
1
33 DF430X-098
Pin, ɸ10×16
2
34 DF430X-099 Push Rod 2
35 56500-145 Tappet 2
36 DF430X-100 Exhaust Valve 1
37 DF430X-101 Intake Vavle 1
38 DF430X-102 Piston Ring Set 1
39 56500-147 Circlip 2
40 DF430X-103 Piston Pin 1
41 DF430X-104 Piston 1
42 DF430X-105
Connecting Rod
Assembly
1
43 DF430X-106 Bolt, M8x32 6
44 56500-159
Oil Seal,
ɸ25xɸ41.25x6
1
45 DF430X-107 Crankcase Cover 1
46 DF430X-108 Gasket, Crankcase 1
47 56500-156
Pin, ɸ8x14
2
48 DF430X-109 Bearing, TM6205 2
49 DF430X-110 Camshaft 1
50 DF430X-111 Crankshaft 1
51 56500-153 Woodruff Key 1
52 DF430X-112 Oil Sensor 1
53 56500-162
O-Ring, ɸ15.8x2.5
1
54 DF430X-113 Dipstick 1
55 DF430X-114 Governor Gear 1
56 DF430X-115 Bolt, M6x12 2
57 DF430X-116
Governor Gear
Bracket Assembly
1
58 DF430X-117 Governor Lever 1
59 56500-168 Cotter Pin 1
60 56500-166
O-Ring, ɸ5.2x1.9
1
39
