SPECIFICATIONS
GENERATOR
ENGINE
Model Number DF472X
Rated Wattage
Gasoline: 3800 Watts
LPG: 3500 Watts
Surge Wattage
Gasoline: 4750 Watts
LPG: 4350 Watts
Phase Single
Frequency 60 Hz
Rated Voltage AC: 120V/240V, DC: 12V
Rated Amperage AC: 32A/16A, DC: 8A
Product Dimensions 23.2 in. x 17.5 in. x 18.5 in.
Product Net Weight 102.5 Pounds
Engine Type 4-stroke, OHV, Single Cylinder
Engine Displacement 224cc
No-Load Speed 3600 RPM
Fuel Tank Capacity 4 US Gallons (15 L), 87 octane minimum
Oil Capacity 20.3 fl. oz. (0.6 L)
Half-Load Run Time
Gasoline: 11 hours
LPG (with 20 lb tank): 7 hours
Spark Plug Type Torch F7TC/NGK BP7ES
Spark Plug Gap 0.7 - 0.8 mm (0.028 - 0.031 in)
Spark Plug Torque
1/2 - 3/4 turn after gasket contacts base or 15
ft-lbs
Length of LPG Hose 47 inches (1200 mm)
3
