Wen DF472X User Manual

EXPLODED VIEW & PARTS LIST
GENERATOR
No. Part No. Description Qty.
1 DF475X-001 Alternator Assembly 1
1.1 DF475-001.3 Rotor 1
1.2 DF475-001.2
Grounding Post
Assembly
1
1.3 DF475-001.1
Carbon Brush
Assembly
1
1.4 DF475-001.4 Stator 1
2 DF475-002 Motor Stand 1
3 DF475-003
Switch Dial
Assembly
1
4 DF475-004
Hexagon Pattern
Pan Head Screws
M6X12
1
5 DF475-005 Nut M8 2
6 DF475X-078
Phillips Head Screw,
M4x28
2
7 DF472X-007 Frame 1
8 DF475-008 Isolator A 2
9 DF475-009 Isolator B 2
10 DF475-045 Nut M6 1
11 DF475X-011 Fuel Tank Assembly 1
11.1 DF475-079 Fuel Tank Filter 1
11.2 DF475-078 Fuel Gauge 1
12 GN4500-012 Fuel Cock 1
13 DF475X-013 Regulator Assembly 1
14 DF475X-014 Regulator 1
15 DF472-015 Foot 4
16 DF475-046 Bolt M816 2
17 DF475-017 Bolt M8-1x220 1
18 DF475-018
Rotor Bolt Gasket
Ø8.5x24x3
1
19 DF475-047 Clip Ø12 2
20 DF475-020 Bolt M6x175 4
21 DF475-021 Bolt M6x12 17
No. Part No. Description Qty.
22 DF472X-022ASM Engine Assembly 1
23 DF475-023 Air Cleaner Bracket 1
24 DF475-024 Exhaust Packing 1
25 DF475-069 Grounding Wire 1
26 DF475-026 Muffler Comp 1
27 DF475-027 Spring Washer Ø8 2
28 DF475X-028
Vibration Isolation
Pad
1
29 DF472X-029ASM
Control Panel
Assembly
1
29.1 DF472-029.1 Engine Switch 1
29.2 DF472X-029.2
CO Sensor Error
LED (Yellow)
1
29.3 DF472X-029.3
CO Sensor Alert LED
(Red)
1
29.4 DF475-029.2 DC Receptacle, 12V 1
29.5 DF475-029.3 DC Breaker, 8A 1
29.6 DF475X-029.4
NEMA 5-20R 120V
20A GFCI Duplex
Outlet
1
29.7 DF475-029.5 AC Breaker, 20A 1
29.8 DF475-029.9 Grounding Lug 1
29.9 DF475-029.6
Voltage Selector
Switch
1
29.10 DF475-029.7 AC Breaker, 16A 1
29.11 DF475-029.8
NEMA L14-30R
125V/250V 30A
Receptacle
2
29.12 DF472-029.10 Panel Rear Cover 1
29.13 DF472X-029.13 Panel 1
30 DF472-030 Fuel Line Clip Ø8.5 2
31 DF475X-066 CO Sensor Module 1
32 DF475X-061 Fuel Line Clip Ø9.5 2
33 DF475-033 Voltage Regulator 1
34 DF475-034 Bolt M5x16 1
35
