Wen DF475X

EXPLODED VIEW & PARTS LIST
ENGINE
No. Part No. Description Qty.
1 DF475-101 Crankcase 1
2 DF475-102 Ball Bearing 2
3 DF475-103 Oil Seal 2
4 DF475-104 Governor Assembly 1
5 DF475-105 Governor Arm Shaft 1
6 DF475-106
Governor Arm Shaft
Washer
1
7 DF475-107 Lock Pin 1
8 DF475-108 Drain Plug Bolt 2
9 DF475-109 Drain Plug Washer 2
10 DF475-110
Oil Level Switch
Assembly
1
11 DF475-111 Bolt M6x16 2
12 DF475-112
Crankcase Cover
Dowel Pin, Ø8x12
4
13 DF475-113 Piston 1
14 DF475-114
Piston Scraper Ring
Set
1
15 DF475-115
Connecting Rod
Assembly
1
16 DF475-116 Piston Pin 1
17 DF475-117 Piston Clip 2
18 DF475-118
Crankcase Cover
Assembly
1
19 DF475-119 Cylinder Head 1
20 DF475-120 In-Valve 1
21 DF475-121 Valve Exhaust 1
22 DF475-122 Intake Valve Returner 1
23 DF475-123 Valve Spring 2
24 DF475-124 In-Valve Spring Seat 1
25 DF475-125 Ex-Valve Spring Seat 1
26 DF475-126 Push Rod Guide Plate 1
27 DF475-127 Rocker Assembly 2
No. Part No. Description Qty.
28 DF475-128 Rotator 1
29 DF475-129 Carburetor Stud Bolt 2
30 DF475-130 Stud Bolt 2
31 DF475-131 Carburetor Assembly 1
32 DF475X-132 Fuel Line 1
33 DF475-133 Fuel Line Clip Ø7.5 1
34 DF475-134 Governor Arm 1
35 DF475X-135 Low Pressure Hose 1
36 DF475-136 Nut M6 2
37 DF475-137 Crankshaft Assembly 1
38 DF475-138 Valve Lifter 2
39 DF475-139 Casecover Packing 1
40 DF475-140 Camshaft Assembly 1
41 DF475-141 Dowel Pin 2
42 DF475-142 Bolt M8x30 6
43 DF475-143 Cylinder Head Gasket 1
44 DF475-144 Bolt M8x60 4
45 DF475-145
Spark Plug, Torch
F7TC (NGK BP7ES)
1
46 DF475-146 Push Rod 2
47 DF475-147 Shroud 1
48 DF475-148 Bolt M6x12 12
49 DF475-149 Headcover Packing 1
50 DF475-150 Cylinder Head Cover 1
51 DF475-151 Wind Shield Assembly 1
52 DF475-152 Bolt M6x28 1
53 DF475X-153 Recoil Starter Fan 1
54 DF475-154 Starter Pulley 1
55 DF475-155 Nut M14 1
56 DF475-156 Ignition Coil Assembly 1
57 DF475-157 Bolt M6x25 2
58 DF475-158
Carburetor Insulator
Gasket
1
