Wen DF480iX - Page 38

EXPLODED VIEW & PARTS LIST
GENERATOR
NO. PART NO. DESCRIPTION QTY.
68 56480iX-068
Remote Start &
Electric Start Module
1
69 56360iX-125 CO Alarm 1
70 56480iX-070
CO Sensor Shield
Housing
1
71 56480iX-071 Grounding Wire 1
72 56480iX-072 Bolt, M4x12 1
73 DF480iX-073 Fuel Hose 1
74 56477i-068 Fuel Hose 1
75 DF480iX-075 Mounting Plate 1
76 DF480iX-076
Self-tapping Screw,
ST4.2x16
2
77 DF480iX-077 Mounting Base 1
78 DF480iX-078 Screw, M2.5x20 2
79 DF480iX-079 Nut, M2.5 2
80 DF480iX-080 Bolt, M6x16 1
NO. PART NO. DESCRIPTION QTY.
81 DF360iX-034
Solenoid Valve
Controller
1
82 DF480iX-082 LPG Quick-connector 1
83 DF480iX-083 Nut, M12 1
84 DF480iX-084 LPG Hose 1
85 DF480iX-085 LPG Hose Jacket 1
86 DF480iX-086 Mounting Plate 1
87 DF480iX-087
Fuel Hose Clamp,
16mm
2
88 DF480iX-088 Clip 1
89 DF480iX-089 Washer, 4mm 1
90 DF480iX-090
LPG Quick-Connector
Cap
1
91 56477i-069 Clamp 1
92 DF480iX-093
Self-tapping Screw,
ST4.2×20
2
N.P. DF480iX-092
LPG Regulator Hose
Assembly
1
