Wen DW5062

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 6369-001 M6x15 Screw 1
2 6369-002 Ø6 Washer 1
3 DW5062-003 Sanding Pad 1
4 6369-004 Output Shaft 1
5 6369-006 Oil Seal 1
6 6369-007 Collar Ø22 1
7 6369-008
Ball Bearing 6900
RS
1
8 DW5062-008 Screw M4x16 6
9 6369-010 Bearing Cover 1
10 6369-011 Paper Washer 1
11 6369-012 End Gear 1
12 6369-014 Ball Bearing 606 Z 2
13 6369-009 Screw M4x12 4
14 6369-015 Small Bearing Cover 1
15 6369-016 Ball Bearing 699 Z 1
16 6369-017 Collar Ø22 1
17 6369-018 Main Driving Shaft 1
18 6369-020
Semi-Circular Key
3X3X10
1
19 6369-019 Washer 1
20 6369-021 Tapered Gear 1
21 6369-022 Washer 1
22 6369-023 Collar Ø9 1
23 6369-024 Gear Box 1
24 6369-026 Rotor Coil 1
25 6369-027 Wool Cap 1
26 6369-025 Middle Cover 1
27 DW5062-027 Anti-Dust Washer 1
28 6369-028 Rotor 1
29 6369-029 Anti-Dust Ring 1
30 6369-030 Ball Bearing 607 RS 1
31 6369-031 Anti-Wind Ring 1
32 6369-032 Screw ST4x55 2
33 6369-033 Washer 1
34 6369-034 Stator 1
35 6369-035 Sleeve 1
36 DW5062-036 Logo Label 1
37 6369-036 Motor Housing 1
No. Part No. Description Qty.
38 DW5062-038 Specification Label 1
39 6369-039 Screw M4x20 4
40 6369-040 Brush Holder 2
41 6369-041 Carbon Brush 2
42 6369-042 Screw ST3x10 2
43 6369-043 Coil Spring 2
44 6369-047
Pressing Block On
Motor Housing
1
45 6369-045 Screw ST4x12 2
46 6369-046 Screw ST4x14 37
47 6369-044 Back Cover 1
48 6369-048 Vibration Damping 2
49 6369-049 Rubber Sleeve 2
50 6369-050 Screw Pin 2
51 6369-051 Flexible Sleeve 1
53 6369-052 Brush Segment 1
54 6369-053 Sanding Pad Cover 1
55 6369-064 Compressed Spring 4
56 6369-063 Washer Ø4 4
57 6369-054 Hose Clamp 25-38 1
58 6369-055 350 Hose 1
59 6369-057 Small Rubber Cover 2
60 6369-062 Left Handle Stand 1
61 6369-059 Ø28 Connector 1
62 6369-060 Plastic Soft Pipe Ø28 1
63 6369-056 Cable Sleeve 1
64 6369-061 Ellipticle Connector 1
65 6369-083 Aluminium Pipe 1
66 6369-080 Ø5 Clinch Bolt 2
67 6369-082 Front Hinge 1
68 6369-081 Ø1.2 Sealed Ring 1
69 6369-079 Ø5x45 Pin 1
70 6369-078 Back Hinge 1
71 6369-085 Pin Ø5x30 1
72 6369-086 Pin Ø5x16.8 1
73 6369-066 Cable Plate 2
74 6369-073 Left Main Handle 1
75 6369-075 Cable Pressing Plate 1
76 6369-069 Potentiometer 1
