Wen DW5062

NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
77 6369-070 Speed Button 1
78 6369-072 Cable Sleeve 1
79 6369-071 Cable 1
80 6369-093 Switch 1
81 6369-094
Switch Pushing
Lever
1
82 6369-097
Circular Pin
Ø1.5x11.8
1
83 6369-095 Switch Button 1
84 6369-098 Back Screw Nut 2
85 6369-077 Aluminium Pipe 1
86 6369-076 Left Sub-Handle 1
87 6369-090 Latch Pivot 1
88 6369-091 Fixed Plate 1
89 6369-084 Supporting Arm 1
90 6369-087 Sleeve 2
91 6369-089 Spring 1
92 6369-088 Front Latch 1
93 6369-058 Right Handle Stand 1
No. Part No. Description Qty.
94 6369-074
Aluminium Pipe
Insert
1
95 6369-092 Aluminium Pipe 1
96 6369-099 Right Main Handle 1
97 6369-096 Right Sub-Handle 1
98 6369-100
Hose Connection
Adapter
1
99 6369-101 Adjustable Ring 1
100 6369-103 Flexible Hose 1
101 6362-054 Middle Connector 1
102 DW5062-102
Ø47 Vacuum
Adapter
1
104 DW5062-104
Shoulder Strap with
hook
1
105 DW5062-105 Hook Seat 1
106 DW5062-106 Nut M5 1
107 DW5062-107 Bolt M5x18 1
108 DW5062-108 Hex Wrench S5 1
