Wen HA5932 User Manual

17
EXPLODED VIEW & PARTS LIST
NO PART NO DESCRIPTION QTY
1 HA5932-001 Nameplate Label 1
2 HA5932-002 Housing, Left 1
3 HA5932-003 Dust Port, 1-1/2" 1
4 HA5932-004 Power Cord 1
5 HA5932-005 Cable Guard 1
8 HA5932-008 Cable Clamp 1
9 HA5932-009 Self-tapping Screw, M4x16 2
10 HA5932-010 Wire Connector 1
11 HA5932-011 Stator 1
12 HA5932-012 Rotor Bushing 1
13 HA5932-013 Carbon Brush 1
14 HA5932-014 Brush Holder 1
15 HA5932-015 Brush Housing 1
16 HA5932-016 Ball Bearing, 626ZZ 1
17 HA5932-017 Rotor 1
18 HA5932-018 Ball Bearing, 608ZZ 1
19 HA5932-019 Drive Pulley 1
20 HA5932-020 V-groove Drive Belt, EPJ206 1
21 HA5932-021 Retaining Ring, 5mm 2
22 HA5932-022 Flat Washer, 5mm 2
23 HA5932-023 Idler Shaft 1
24 HA5932-024 Needle Bearing, HK0509 1
25 HA5932-025 Idler Pulley 1
26 HA5932-026 Hex Nut, M8-1.25 1
27 HA5932-027 Large Poly-V Pulley 1
28 HA5932-028 Ball Bearing 608Zz 1
29 HA5932-029 Intermediate Shaft 1
30 HA5932-030 Small Timing-Belt Pulley 2
31 HA5932-031 Stop Collar 1
32 HA5932-016 Ball Bearing, 626ZZ 1
33 HA5932-033 Self-tapping Screw, M4x12 6
34 HA5932-034 Base Plate Cover 1
35 HA5932-035 Base Plate 1
36 HA5932-036 PCB 1
37 HA5932-037 Cap 3
38 HA5932-038 Rubber Pad 5
39 HA5932-039 Self-tapping Screw, M2x10 1
40 HA5932-040 Power Switch 1
41 HA5932-041 Timing Belt, XL100 2
42 HA5932-042 Housing, Right 1
43 HA5932-009 Self-tapping Screw, M4x16 13
NO PART NO DESCRIPTION QTY
44 HA5932-044 Secondary Label 1
45 HA5932-045 Ball Bearing, 6004ZZ 2
46 HA5932-046 Transmission Pulley 1
47 HA5932-047 Differential Pulley 1
48 HA5932-048 Output Shaft 1
49 HA5932-049 Flat Washer, 4mm 1
50 HA5932-050 Needle Bearing 1
51 HA5932-051 Clevis Pin, 4x24mm 1
52 HA5932-052 Differential Wheel Cover 1
53 HA5932-009 Self-tapping Screw, M4x16 3
54 HA5932-054 Guide Plate 1
55 HA5932-055 Knob, M5x18 2
56 HA5932-056 Fender Washer, 1/2" 1
57 HA5932-057 Fender Washer, 6mm 1
58 HA5932-058 Knob, M6x12 1
59 HA5932-059
Rubber Sanding Drum,
1-1/2" x 3"
1
60 HA5932-060
Rubber Sanding Drum,
1" x 3"
1
61 HA5932-061
Rubber Sanding Drum,
3/4" x 3"
1
62 HA5932-062 Sanding Sleeve, 1-1/2" x 3" 1
63 HA5932-063 Sanding Sleeve, 1" x 3" 1
64 HA5932-064 Sanding Sleeve, 3/4" x 3" 1
64 HA5932-065 Sanding Sleeve, 1/2" x 3" 1
66 HA5932-066 Mounting Pad 1
67 HA5932-067 Mounting Clamp Assembly 2
101
HA5932-
101ASM
Stator Assembly 1
102
HA5932-
102ASM
Carbon Brush Assembly 2
103
HA5932-
103ASM
Rotor Assembly 1
104
HA5932-
104ASM
Idler Pulley Assembly 1
105
HA5932-
105ASM
Intermediate Shaft Assembly 1
106
HA5932-
106ASM
Output Shaft Assembly 1
107
HA5932-
107ASM
Sanding Sleeve Set 1
108
HA5932-
108ASM
Mounting Assembly 1
