KNOW YOUR BELT SANDER
1
TOOL PURPOSE
Easily shape and finish wood and other materials with your WEN Handheld Belt Sander. Refer to the following dia-
grams to become familiarized with all the parts and controls of your tool. The components will be referred to later
in the manual for assembly and operation instructions.
3
2
5
6
7
9
10
8
1. Front Handle
2. Drive Belt Cover
3. Tracking Adjustment Knob
4. Variable Speed Wheel (HB632V Only, Not Shown)
5. Continuous Running Switch
6. Dust Extraction Port
7. ON / OFF Trigger Switch
8. Rear Handle
9. Belt Tensioning Lever
10. Front Roller
11. Dust Collection Bag
11
10
4
