EXPLODED VIEW & PARTS LIST
14
No. Part No. Description Qty.
1 HG112V-001 Housing 1
2 HG112V-002 Left Housing 1
3 HG112V-003 PCB 1
4 HG112V-004 Motor Assembly 1
4.1 HG112V-004.1 Motor 1
4.2 HG112V-004.2 Motor Support 1
4.3 HG112V-004.3 Screw 2
4.4 HG112V-004.4 Fan 1
5 HG112V-005 Screw 3
6 HG112V-006 Fan Cover 1
7 HG112V-007 Heating Element Assembly 1
7.1 HG112V-007.1 Heat Cover 1
7.2 HG112V-007.2 Mica Sheet 2
7.3 HG112V-007.3 Heating Element 1
8 HG112V-008 Switch 1
9 HG112V-009 Switch Cover 1
10 HG112V-010 Terminal Block 1
11 HG112V-011 Power Cord Clamp 1
12 HG112V-012 Screw 2
13 HG112V-013 Power Cord Strain Relief 1
14 HG112V-014 Power Cord 1
15 HG112V-015 Support Ring 1
16 HG112V-016 Front Cover 1
17 HG112V-017 Right Housing 1
18 HG112V-018 Screw 6
