Wen JT3062

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 Table 2
2
Socket Head Cap
Screw, M8x30
8
3 Outfeed Support 1
4 Set Screw, M6x8 8
5 JT630H-005 Left Cover 1
6
Round Head Allen
Screw, M6x12
19
7
Round Head Self-Tap-
ping Allen Screw
4
8 Warning Label 1
9 Foam Seal 1
10 Dust Chute 1
11 Logo Label 1
12 Front Frame 1
13 JT630H-013 Dust Port 1
14_S Bearing Retainer Assy. 1
17 C-Ring 1
18 JT3062-018 Cutterhead Lock 1
20 Pointer 1
21 Gear 1
22 Depth Scale 1
23 Lock Knob, M8x18 2
24 Flat Washer, 8mm 3
25 Foot 4
26 Ext. Retaining Ring 1
27 Screw, M5-0.8x8 2
27a Lock Washer, 5mm 2
27b Hex Nut, M5 2
28 Screw, M5-0.8x25 4
28a
Anti-Loose Hex Nut,
M5
4
29 Switch Box 1
34 Rear Frame 1
35 Hole Plug 4
36_S Bearing Retainer Assy. 1
39a Cutterhead Pulley 1
40 JT630H-040 Belt, 125J5 1
41 Belt Guard 1
48 Flange Nut, M6 16
No. Part No. Description Qty.
49 Support Rod 8
50 Cord Clamp 1
51_S
Infeed Support As-
sembly
1
62 Right Cover 1
64 Hex Nut, M8 1
70 JT630H-070 Jointer Push Block 2
71 JT630H-071 2.5mm Hex Wrench 1
72 JT630H-072 4mm Hex Wrench 1
73
Button Head Screw,
1/4"-20x5/8"
8
74 JT3062-074 Gib 2
75 JT3062B Blade 2
76 Spacer 1
77_S Cutterhead 1
100 Hole Plug 1
101_S
JT630H-
101ASM
Guard Assembly 1
102d Blade Guard Label 1
125 JT630H-125 Fence 1
126 Warning Label 1
128 Bevel Bracket 1
129 Square Nut 2
130 Rectangle Nut 1
130a Rectangle Fence Nut 1
131 Set Screw M5-0.8x8 2
132 Intermediate Bracket 1
133S
JT630H-
133ASM
30 mm Tilt Lock Lever
Assy.
1
135S
JT630H-
135ASM
40 mm Tilt Lock Lever
Assy.
1
136 JT630H-136 Fence Slide Bracket 1
137 JT630H-137 Fence Bracket 1
138 Flat Washer, 6mm 3
139 Screw, M6x16 6
140 Main Label 1
319 Brush Holder 2
320 JT630H-320 Carbon Brush 2
321 Brush Cover 2
