Wen LA3424

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 3424-001 Rear Spindle Wheel 1
2 3424-002 Set Screw 2
3 3424-003 Ball Bearing, 6004ZZ 1
4 3424-004 Retaining Ring 1
5 3424-005 Headstock 1
6 3424-006 Rear Cover 1
7 3424-007
Rear Cover Locking
Knob
1
8 3424-008 Screw, M6x16 1
9 3424-009 Retaining Ring 1
10 3424-010 Ball Bearing, 6005ZZ 1
11 3424-011 Key 1
12 3424-012 Spindle Shaft 1
13 3424-013 Face Plate 1
14 3424-014 Spur Center 1
15 3424-015 Live Center 1
16 3424-016 Quill 1
17 3424-017 Screw Stem 1
18 3424-018 Retaining Ring 1
19 3424-019 Tailstock 1
20 3424-020 Set Screw 1
21 3424-021 Quill Locking Handle 1
22 3424-022
Tailstock Locking
Lever
1
24 3424-024 Handle 1
25 3424-025 Handle Screw 1
26 3424-026 Handwheel 1
27 3424-027 Set Screw 2
28 3424-028 Tailstock Drawbar 1
29 3424-029 Retaining Ring 1
30 3424-030 Tool Rest Drawbar 1
31 3424-031
Tool Rest Locking
Handle
1
32 3424-032-1 Tool Rest Base 1
33 3424-033 Retaining Ring 1
34 3424-034-1 Tool Rest 1
35 3424-035 Set Screw 1
36 3424-036
Tool Rest Locking
Lever
1
37 3424-037 Drive Belt 1
No. Part No. Description Qty.
38 3424-038 Spindle Pulley 1
39 3424-039
Headstock Mounting
Screw
1
40 3424-040 Lock Washer 4
41 3424-041 Set Screw 1
42 3424-042 Bushing 1
43 3424-043
Side Cover Locking
Knob
1
44 3424-044 Side Cover 1
45 3424-045 Screw, M6x16 2
46 3424-046-1 Base 1
47 3424-047
Threaded Foot, M8-
1.25
4
48 3424-048 Set Screw 2
49 3424-049 Motor Pulley 1
50 3424-050
Motor Mounting
Screw
4
51 3424-051 Lock Washer 4
52 3424-052 Motor Support Plate 1
53 3424-053 Flat Washer 1
54 3424-054
Motor Plate Lock
Handle
1
55 3424-055 Flat Washer 1
56 3424-056 Lock Washer 1
57 3424-057 Hex Head Bolt 1
58 3424-058 Cord Clamp 3
59 3424-059
Pan Head Screw,
M5x10
3
60 3424-060 Motor 1
61 3424-061 Clamp Plate 1
62 3424-062 Nut, M10 1
63 3424-063-1 Switch Plate 1
64 3424-064 Switch 1
65 3424-065-1
Pan Head Screw,
M5x12
4
66 3424-066-1 Switch Housing 1
67 3424-067 Bushing 2
68 3424-068 End Stop Plate 1
69 3424-069
Pan Head Screw,
M8x12
2
