Wen LA3424

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
70 3424-070 Strain Relief 1
71 3424-071 Power Cord 1
72 3424-072
Pan Head Screw,
M5x10
2
73 3424-073 Lock Washer, 5mm 2
74 3424-074 Flat Washer, 5mm 2
75 3424-075 Grounding Terminal 2
76 3424-076 Serrated Washer 2
77 3424-077 3mm Hex Wrench 1
78 3424-078 5mm Hex Wrench 1
79 3424-079 Face Plate Wrench 1
80 3424-080 Knockout Rod 1
No. Part No. Description Qty.
81 3424-081 Tool Holder 1
82 3424-082
Pan Head Screw,
M5x12
2
83 3424-083 Sealing Plate 1
84 3424-084 Rubber Ring 1
85 3424-085 Handle Cover 1
86 3424-086 Circuit Breaker, 5A 1
87 3424-087
Bushing Mounting
Plate
1
88 3424-088
Pan Head Screw,
M5x12
2
