ASSEMBLY & ADJUSTMENTS

EXPLODED VIEW & PARTS LIST

No. Part No. Description Qty

1 LA8800-001 Mounting Platform 2

2 LA8800-002 Washer M10 24

3 LA8800-003 Hex Bolt M10x80 12

4 LA8800-004 Hex Nut M10 12

5 LA8800-005 Column 2

6 LA8800-006 Inner Beam 1

7 LA8800-007 Hex Bolt M10x20 2

8 LA8800-008 Outer Beam 1

9 LA8800-009 Hex Bolt M12x100 4

10 LA8800-010 Hex Nut M12 4

11 LA8800-011 Washer M12 8

12 LA8800-012 Base 2

13 LA8800-013 Washer M12 4

14 LA8800-014 Rubber Foot 4

15 LA8800-015 Clip 4
