Wen LA8800 User Manual

6
PACKING LIST
Check your packing list against the diagram below. If any part is damaged or missing, please contact
our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com.
Tools needed for assembly (not included): Adjustable Wrench and pliers OR socket set, bubble level
KNOW YOUR LATHE STAND
1
2
3
Mounting Platform (2)
Washer M10 (24)
Hex Bolt M10x80 (12)
Hex Nut M10 (12)
Column (2)
Inner Beam (1)
Hex Bolt M10x20 (2)
Outer Beam (1)
Hex Bolt M12x100 (4)
Hex Nut M12 (4)
Washer M12 (8)
Base (2)
Washer M12 (4)
Rubber Foot (4)
Clip (4)
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
4
5
6
7
8
9
10
11
12
13
14
15
230 mm
110 mm
52.5 mm
67 mm
11 mm
90 mm

Wen LA8800 Specifications

General

Brand	Wen
Model	LA8800
Category	Lathe
Language	English
