EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 PW22-001 ON / OFF Switch 1
2 PW22-002 ON / OFF Switch Silver Ring 1
3 PW22-003 Upper Housing Panel 1
4 PW22-004 Center Housing Panel 1
5 PW22-005 Front Outlet Cover 1
6 PW22-006 Lower Housing Panel 1
7 PW22-007 Front Housing 1
8 PW22-008 Screw ST2.9 x 12 14
9 PW22-009 Screw ST2.9 x 20 4
10 PW22-010 Front On / Off Switch Case 1
11 PW22-011 Capacitor 1
12 PW22-012 Double Plug 2
13 PW22-013 Protective Sleeve 2
14 PW22-014 Main Switch 1
15 PW22-015 Rear ON / OFF Switch Case 1
16 PW22-016 Switch Lever 1
17 PW22-017 Switch Lever O-Ring 1
18 PW22-018 Motor Cover 1
19 PW22-019 Support Bushing 4
20 PW22-020 Screw ST4 x 14 2
21 PW22-021 Cord Case 1
22 PW22-022 Power Cord Sleeve 1
23 PW22-023 Wheel 2
24 PW22-024 Wheel Cap 2
25 PW22-025 Water Inlet Filter 1
26 PW22-026 Rear Outlet Cover 1
27 PW22-027 Screw ST3.9 x 25 8
28 PW22-028 Rear Housing 1
29 PW22-029 Gun Holder 1
30 PW22-030 Motor Assembly 1
31 PW22-031 Pump Assembly 1
32 PW22-032 Power Cord 1
33 PW22-033 Wire Terminal 2
34 PW22-034 Wire Terminal Sleeve 2
35 PW22-035 Power Cord Hook 2
36 PW22-036 Screw ST3.9 x 25 2
37 PW22-037 High Pressure Gun 1
38 PW22-038 High Pressure Hose 1
39 PW22-039 Nozzle Cleaner 1
40 PW22-040 Clip 1
41 PW22-041 Connect Hose 1
42 PW22-042 Vertical Joint 1
NO. PART NO. DESCRIPTION QTY.
43 PW22-043 O-Ring 2.7 2
44 PW22-044 Split Ring 2
45 PW22-045 Stainless-Steel End Cap 1
46 PW22-046 Screw M3.9 x 15 3
47 PW22-047 Straight Joint 1
48 PW22-048 Left Cover 1
49 PW22-049 Bolt M5 x 42 2
50 PW22-050 Front Handle 1
51 PW22-051 Handle Tube 2
52 PW22-052 Hose Reel Cap 2
53 PW22-053 Nut M5 2
54 PW22-054 Washer M5 2
55 PW22-055 Hose Reel 2
56 PW22-056 Screw ST4 x 25 4
57 PW22-057 Rear Handle 1
58 PW22-058 Screw M3.9 x 16 4
59 PW22-059 Screw ST3.9 x 15 8
60 PW22-060 Right Cover 1
61 PW22-061 Screw ST4 x 50 4
62 PW22-062 Upper Bolt 1
63 PW22-063 Handle Base 1
64 PW22-064 Lower Bolt 1
65 PW22-065 Handle Core 1
66 PW22-066 Handle 1
67 PW22-067 Handle Cover 1
68 PW22-068 Screw ST2.9 x 16 1
69 PW22-069 Bolt M5 x 45 2
70 PW22-070 Left Support Holder 1
71 PW22-071 Bolt M5 2
72 PW22-072 Screw ST3.9 x 25 4
73 PW22-073 Right Support Holder 1
74 PW22-074 Detergent Bottle Cap 1
75 PW22-075 Detergent Bottle 1
76 PW22-076 Detergent Bottle Bracket 1
77 PW22-077 Detergent Hose 1
78 PW22-078 Detergent Hose Clip 1
79 PW22-079 Detergent Filter 1
80 PW22-080 Water Inlet Connector 1
81 PW22-081 GFCI Power Plug 1
82 PW22-082 Rear Handle Cover 1
83 PW22-083 Front Handle Cover 1
84 PW22-084 Screw ST3.9 x 16 3
