Werner Weitner WW-1 - Technical Data; Model Specifications

Seite 17 von 18 WH-1, WH-2, WH-3, WH-4
Werner Weitner GmbH, Sollnau 14, D-85072 Eichstätt / Bay., service phone 08421/9816-0, fax 08421/9816-98
15 Warranty conditions
Please refer to the general terms and conditions of Werner Weitner GmbH, Sollnau 14, D-85072 Eichstätt / Bay., Germany.
16 Technical data
16.1 Oil recommendations
For hydraulic devices, use mineral oil in accordance with DIN 51 524 and others
Range of oil temperature Viscosity rating Remarks
A - 24 ... + 30°C HL 5
B - 18 ... + 50°C HLP 10
C - 8 ... + 75°C HLP 22
D + 5 ... + 80°C HLP 32
Recommended viscosity range: 10…200 mm²/s, delivered with HLP 10 to DIN 51 524.
Type
Order no.
+ 580 + 580
- 145 - 145
Oil capacity / usable oil capacity (l)
Oil delevery (LP / HP ) cm³
Switch over (psi)
Dimensions LxBxH (mm)
Weight with oil (kg)
Type
Order no.
+ 580 + 580
- 145 - 145
Oil capacity / usable oil capacity (l)
Oil delevery (LP / HP ) cm³
Switch over (psi)
Dimensions LxBxH (mm)
Weight with oil (kg)
Operating pressure (psi)
Operating pressure (psi)
WH-1
WH-1 / Operating pressure
WH-3
WH-3 / Operating pressure
0,7 / 0,5
290
WH-2
WH-2 / Operating pressure
5800 - 10150 5800 - 10150
290
1,3 / 0,9
7,2 / 0,9 per piston stroke 17 / 1,7 per piston stroke
WH-4
WH-4 / Operating pressure
5800 - 10150
353 x 150 x 171 564 x 150 x 171
5800 - 10150
4,3 5,3
290 290
2,5 / 1,8 4,9 / 3,8
7,5 10,5
588 x 150 x 171 588 x 186 x 171
18 / 1,7 per piston stroke 19 / 1,7 per piston stroke
