Seite 1 von 18 WH-1, WH-2, WH-3, WH-4

Betriebsanleitung

Hydraulische Handpumpe

1 - 9

10 - 18

WW – WH – 1

WW – WH – 2

WW – WH – 3

WW – WH – 4

1 Ablassventil

2 Anschluss P (NPT 3/8“)

3 Entlüftung- / Einfülldeckel

4 Verriegelung

5 Anschraubbohrungen für Erweiterungssätze

6 Pumpenhebel

7 Niederdruckventil 20 bar

8 Hochdruckventil max. 700 bar

Ausgabe 02.10

WH

-

1 / WH

-

2

WH

-

3 / WH

-

4
