This section explains how to adjust the inversion table. See DEVELOPING A PROGRAM on page 16 for impor-

ant information about how to get the most benefit from using the inversion table.

Make sure that all parts are properly tightened each time the inversion table is used. Replace any worn parts

immediately. The table can be cleaned with a damp cloth and mild, non-abrasive detergent; do not use sol-

vents.

SELECTING A PIVOT BAR POSITION

See the inset drawing. The Pivot Bars (23) have

three adjustment holes. The correct hole to use

depends on your body weight and the desired level

of responsiveness. See the chart at the right to

determine which hole to use. For example, if you

weigh between 120 and 220 pounds and you are a

beginner, the chart recommends that you use hole

To adjust the Pivot Bars (23), first see assembly

step 10 on page 10 and remove the Wingnuts (46)

and the Left and Right Covers (11, 12).

Next, lift a Pulley (29) out of a Saddle Plate (not

shown). Move the Pivot Bar (23) so that the pin on

the Backrest Frame (1) is in the desired adjustment

hole. Then, slide the Pulley into the slot in the

Saddle Plate. Adjust the other Pivot Bar in the

same way.

See assembly step 10 on page 10. Reattach the

Covers (11, 12) with the Wingnuts (46).

Try the inversion table with the Pivot Bars (23)

adjusted to each position to find which one is best

for you.

WARNING: Always engage the

pins on the Backrest Frame (1) into the

same holes in both Pivot Bars (23).

ADJUSTMENT

Note: 1 lb. = 2.2 kg

Hole C

Hole B

Hole A
