6
1.
Open the Front and Rear Frames (5, 6) and
push downward on the Long and Short Linking
Bars (7, 8) so that they are in a straight position
as shown.
1
6
5
8
8
7
7
ASSEMBLY
To make assembly easier, carefully read the fol-
lowing information and instructions:
•
Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until assembly is completed.
• Make sure all parts are oriented as shown in the
drawings.
• Tighten all parts as you assemble them, unless
instructed to do otherwise.
• The following tools (not included) may be required
for assembly:
t
wo adjustable wrenches
one rubber mallet
one standard screwdriver
one Phillips screwdriver
Assembly may be more convenient if you have a
socket set, a set of open-end or closed-end
wrenches, or a set of ratchet wrenches.
Before beginning assembly, make sure
that you understand the information in
the box above.
