Weslo WETL91072 Cadence 910 User Manual

PART LISTÑModel No. WETL91072 R0299A
Note: Ò#Ó indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of the userÕs manual for information about ordering replacement parts.
Key No. Qty. Description
1 1 Hood
2 1 Adhesive Clip
3 1 Motor Belt
4 1 Motor Pivot Nut
5 1 Pulley/Flywheel/Fan
6* 1 Motor/Pulley/Flywheel/Fan
7 1 Motor
8 1 Reed Switch
9 16 Clip Screw
10 1 Reed Switch Clip
11 4 Console Base Nut
12 4 Hood Anchor
13 2 Front Roller Bolt
14 1 Magnet
15 6 Platform Screw
16 1 Motor Tension Nut
17 1 Front Roller/Pulley
18 1 Motor Tension Bolt
19 1 Circuit Breaker
20 1 Reed Switch Bracket
21 1 Frame
22 1 Receptical
23 1 Controller
24 1 Motor Pivot Bolt
25 14 Latch Screw/Guide Screw
26 1 Choke
27 1 Electronics Bracket
28 4 Base Leg Bolt
29 2 Roller Guard Screw
30 2 Wheel Nut
31 4 Base Leg Pad
32 2 Base Leg Endcap
33 2 Wheel Bolt
34 2 Wheel
35 1 Allen Wrench
36 2 Frame Pivot Bolt
37 1 Upright
38 1 Storage Latch
39 2 Latch Spring
40 14 Screw
41 2 Handrail Cover
42 1 Key Clip
43 1 Latch Decal
44 1 Filter
45 1 Console Base
46 1 Frame Guide Spacer
47 1 Console Cover
48 1 Battery Cover
49* 1 Console Assembly
50 1 Speed Potentiometer
Key No. Qty. Description
51 1 Speed Control Knob
52 5 Ground Screw
53 1 Wire Harness
54 1 Grommet
55 2 Base Leg
56 7 Belly Pan Fastener
57 1 Belly Pan
58 2 Upright Spacer
59 1 Motor Tension Washer
60 1 Left Foot Rail
61 6 Frame Pivot Nut/Base Leg Nut
62 2 Belt Guide
63 2 Wire Clip
64 1 Right Foot Rail
65 2 Roller Guard
66 2 Frame Guide
67 2 Foot
68 6 Pivot Washer/Base Leg Washer
69 1 Right Endcap
70 2 Rear Roller Adj. Bolt
71 4 Roller Adjustment Washer
72 1 Rear Roller
73 1 Ground Wire
74 1 Walking Platform
75 1 Walking Belt
76 1 Releaseable Tie
77 2 Cable Tie Screw
78 2 Cable Tie Clamp
79 4 8Ó Cable Tie
80 1 Motor Star Washer
81 2 Front Roller Nut
82 1 Latch Bracket
83 1 Left Endcap
84 1 Motor Pivot Sleeve
85 2 Motor Pivot Bushing
86 1 Grounding Screw
87 1 Grounding Star Washer
88 4 Nylon Washer
89 1 Grounding Nut
90 4 Console Base Washer
91 4 Console Base Bolt
92 1 Bracket
# 1 10Ó Black Wire, 2 Female
# 1 8Ó Black Wire, Male/Female
# 1 4Ó Black Wire, 2 Female
# 2 10Ó White Wire Harness
# 1 8Ó Green/Yellow Wire
# 1 4Ó Green/Yellow Wire
# 1 UserÕs Manual
34
REMOVE THIS EXPLODED DRAWING
AND PART LIST FROM THE MANUAL
Save this EXPLODED DRAWING and PART LIST for future reference.
Note: Specifications are subject to change without notice. For information about
ordering replacement parts, see the back cover of the UserÕs Manual.
