Westco 4500 - Replacement Parts List for M;S Manual Back-Up Assembly

39
REPLACEMENT PARTS LIST
FOR M/S MANUAL BACK-UP ASSEMBLY
Ref. #
Part Number
No.
Req’d
Description
127
992012-36
4
Cotter Pin 1.900 – 4 ½”
127
992012-36
5
Cotter Pin 4 ½” – 6 1/8”
206
45206
1
Latch Spring 1.900 – 4 ½”
206
45206
2
Latch Spring 4 ½” – 6 1/8”
209
45209
2
Die
45266
1
Lever 1 5/16” – 2 1/16”
267
45267
1
Lever 1.900 – 4 ½”
267
45578
1
Lever 4 ½” – 6 1/8”
295
992015-02
2
Socket Screw
359
45359
3
Hanger Pin Assy
360
992047-12
3
Hair Pin
572
45572
1
Lever Latch
572
45577
1
Lever Latch, Short 4 ½” – 6 1/8”
421
45421
1
Long Jaw
422
45420
1
1.31 – 2.06 Lug Jaw
422
45422
1
2 3/8” – 3.668 Lug Jaw
422
45424
1
3 ½” – 4 ½” Lug Jaw
422
45579
1
4 ½” – 5 ¼” Lug Jaw
422
45580
1
5.200 – 6 1/8” Lug Jaw
494
45494
2
Hinge Pin 1.900 – 4 ½”
494
45494
5
Hinge Pin 4 ½” – 6 1/8”
573
45573
1
Long Spring (Left)
574
45574
1
Short Spring (Right)
575
45575
2
Hinge Pin
591
992008-18
7
Screw
622A
45622-5
Inner/Outer Sleeve Assy (Ref. 622, 623, 643, 591, 359)
622
45622
1
Outer Sleeve
623
45623
1
Inner Sleeve
624
45624
1
Lever, Bar
643
945031-64
2
Suspension Spring
45715-100
1
Back-up Assy Complete with 1.31–2.06 Lug Jaw
45700
1
Back-up Assy Complete with 2 3/8” – 2 7/8”
Lug Jaw
45720
1
Back-up Assy Complete with 3 ½” – 4 ½” Lug
Jaw
45725-100
1
Back-up Assy Complete with 4 ½” – 5 ¼” Lug
Jaw
45745-100
1
Back-up Assy Complete with 5.200 – 6 1/8”
Lug Jaw
45715-200
1
Lever Latch Sub Assy 1.31 – 2.06
45730
1
Lever Latch Assy Complete with 2 3/8” – 2 7/8” Lug Jaw
45740
1
Lever Latch Assy Complete with 3 ½” – 4 ½”
Lug Jaw
45725-200
1
Lever Latch Sub Assy with 4 ½” – 5 ¼ Lug Jaw
45745-200
1
Lever Latch Sub Assy with 5.200 – 6 1/8” Lug
Jaw
