5.3. Type Tests and Environmental Conditions
Environmental
phenomena
Basic standard
Description Test levels
ESD EN 61000-4-2 Enclosure Contact: ±6 kV
Air: ±8 kV
RF field AM modulated IEC 61000-4-3 Enclosure 10 V/m (80-2700 MHz)
Fast transients EN 61000-4-4 Signal ports MRD-415: ± 1 kV
MRD-455: ± 2 kV
Power ports ± 2 kV
Surge EN 61000-4-5 Signal ports MRD-415: ± 1 kV (Crit. B)
MRD-455: ± 2 kV
Power ports MRD-415: ± 0.5 kV (Crit. B)
MRD-455: ± 2 kV
Conducted RF immunity EN 61000-4-6 All ports 10 V (0.15-80 MHz)
Conducted magnetic fields EN 61000-4-8 Only MRD-455 10 A/m
DC voltage dips EN 61000-4-29 12 VDC and 24 VDC up to
300 ms (A), 1s (B)
Radiated RF emission CISPR 16-2-3
ANSI C63,4
(FCC part 15)
Enclosure Class B
Conducted RF emission CISPR 16-2-1
ANSI C63,4
(FCC part 15 b)
Signal ports Class B
Power ports
Table 8. EMC and electrical conditions
20 MRD-415 and MRD-455
