Westermo TD-36 - Interface Specifications

13
6618-2202
Interface specifications
Power AV
Rated voltage 20 to 250 VDC
24 to 240 VAC
Operating voltage 18 to 300 VDC
22 to 264 VAC
Rated current
125 mA @ 18 VDC
15 mA @ 110 VDC
8 mA @ 250 VDC
120 mA @ 22 VAC
35 mA @ 95 VAC
28 mA @ 240 VAC
Rated frequency DC: –
AC: 48 – 62 Hz
Inrush current I
2
t 0.45 A
2
s
Startup current* 0.25 A
peak
Polarity Polarity independent
Isolation to All other ports 3 kV
rms 50 Hz 1 min
Connection Detachable screw terminal
Connector size 0.2 – 2.5 mm
2
(AWG 24-12)
Shielded cable Not required
Power LV
Rated voltage 12 to 48 VDC
12 to 27 VAC
Operating voltage 10 to 60 VDC
10 to 30 VAC 48 – 62 Hz
Rated current 150 mA @ 12 VDC
70 mA @ 24 VDC
40 mA @ 48 VDC
150 mA @ 12 VAC
70 mA @ 24 VAC
Rated frequency DC: –
AC: 48 – 62 Hz
Inrush current I
2
t 0.25 A
2
s
Startup current* 0.30 A
peak
Polarity Polarity independent
Isolation to All other ports 3 kV
rms 50 Hz 1 min
Connection Detachable screw terminal
Connector size 0.2 – 2.5 mm
2
(AWG 24-12)
Shielded cable Not required
* External supply current capability for proper startup
