Configure the TD-36 485
AT&F Set the unit to factory default
AT&W Store default settings
AT*WIOP=10,50,2,3,1 Set I/O params
Min pulse time = 100 ms (10)
Pulse repetition = 500 ms (150)
Trig type = Pulsed trigged (2)
Pulse trig type = POS, pos edge (3)
Output type = output enabled (1)
AT*WIOL=1,2,5,0,0,”0704
28000”, “Temp. high server
room”,”+4670500899”,1, “password”
Define SMS message on entry 1
Entry = 1 (1)
Service = SMS (2)Retry = NEXT_ALLWAYS(5)
Timeout = 0
Priority = 0
Data 1 = SMS receiver number (070428000)
Data 2 = SMS text (Temp. high server room)
Data 3 = Service center Adress (+4670500899)
Data 4 = SMS protocol UDP (1)
AT*WIOL=2,7,2,60,0,+4616480250 Define Transparent I/O on entry 2
Entry = 2 (2)
Service = TRANS (7)
Retry =RETRY_3 (2) ;Do 3 connection attempts
Timeout = 600s (60)
Priority = 0
Data 1 = Phone number of the remote IDW-90
(+4616480250)
Configure the IDW-90
S3:1,3,4 OFF S3:2 ON V.110 configured for GSM
To make switch setting active the power must be cycled OFF -> ON.
Activate events – The sending modem
IO input pulsed with one puls SMS message transferred and transparent IO established
Testing by simulating the event
AT*WIOT=1 Force sending of SMS-message at entry 1
AT*WIOT=2 Force the transparent I/O connection to be established.
