Westermo TR-36 - S5 DIP-Switch: RS-422;485 Termination

19
6614-2202
ON
1 2 3 4 5 6 7 8
S1
ON
1 2 3 4 5 6 7 8
S3
ON
1 2 3 4
S5
ON
1 2 3 4 5 6 7 8
S2
ON
1 2 3 4 5 6 7 8
S4
Factory settings
S5 DIP-switch
RS-422/485 termination
ON
1 2 3 4
No termination
ON
1 2 3 4
Termination of R in 4-wire
connection
ON
1 2 3 4
Termination of both T and R
in 2-wire connection
ON
1 2 3 4
Termination of both T and R
in 4-wire connection
